8-1/4 " Circular Saw
Owner's Manual Parts Breakdown Print Email to Friend


Electric Brake

Model No: 5008MGA

Cutting Depth Capacity Of 3" (75.5mm)

High Performance Magnesium Blade Case And Base

  • Electric Brake for operator safety
  • Dual LED Job Lights illuminate cut line
  • Blower feature keeps cutting line free of sawdust
  • Bevel Capacity of 50o with Positive Stops at 22.5°, 45°, and 50°
  • Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

STANDARD EQUIPMENT

INCLUDES: 8-1/4" C.T. Blade 24T (D-21521), Hex Wrench 6 (783204-6), Guide Rule (164095-8)


SPECIFICATIONS


Blade Diameter

 8-1/4” (210 mm)

Arbor

 5/8” (15.88 mm)

Maximum Cutting Capacities:

  0°

 3” (75.5 mm)

  45°

 2-1/4” (57 mm)

  50°

 2” (51.5 mm)

No Load Speed

 5,200 RPM

AMPS (120V)

 15.0 A

Vibration Level

 3.0 m/s2

Noise Level

 95 dB

Overall Length

 13-1/8” (332 mm)

Net Weight

 11.2 lbs (5.1 kg)

Shipping Weight

 15.2 lbs (6.9 kg)

Related Accessory(ies)

8-1/4" Circular Saw Blades
8-1/4


Segmented-Continuous Rim Diamond Blades
Segmented-Continuous Rim Diamond Blades


Cord Holders
Cord Holders


Note:Makita Canada reserves the right to change specification of products without notice. The contents of the parts breakdown and Instruction manuals may be different from current products.
