AN902

3-1/2" Framing Coil Nailer

15° Round Head Coil Framing Nailer


  • Reduced size for improved handling and optimal maneuverability during operation
  • 2 Mode - Sequential, Bump Fire
  • 8 depth nailing settings in 1/32" increments with adjustment knob
  • One touch and easy to load magazine
  • Rubberized Grip for increased comfort during prolonged use

Items Included:Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)

  • Reduced size for improved handling and optimal maneuverability during operation
  • 2 Mode - Sequential, Bump Fire
  • 8 depth nailing settings in 1/32" increments with adjustment knob
  • One touch and easy to load magazine
  • Rubberized Grip for increased comfort during prolonged use

Items Included: Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)

Shipping Dimensions (Length x Width x Height) & Weight : 16.42 In. X 17.36 In. X 12.99 In. Weight : 9.9 Lb.

Specifications

Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4" - 3-1/2" (45 - 90 mm)
Nail Type .099" - .150" 15° Round Head
Magazine Capacity 150 - 300 Nails
Vibration Level 2.52 m/s2
Noise Level 98.3 dB(A)
Dimensions (L x W x H) 12-1/2" x 5" x 14-1/4" (318 mm x 128 mm x 363 mm)
Net Weight 7.7 lbs (3.5 kg)
