DBN500Z

18V LXT 2" 18 ga Brad Nailer, Tool Only

Bump & Sequential Fire Operating Modes


LXT Technology 18V Battery
  • DC motor and driving mechanism design provides long service life for maximum jobsite durability and performance
  • Reduced reaction force enables maximum operator control and reduced operator fatigue
  • Anti-dry fire mechanism prevents added wear on the drive pin
  • Easy to see, low profile contact tip for maximum fastening precision
  • Rubber bumpers protect tool and materials from damage
  • Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
  • LED battery capacity warning light indicates ideal time to recharge battery
  • LED job light illuminates work area
  • On-board depth control for quick and easy adjustment
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included:Tool Only. Batteries and Charger Sold Separately. Nose Adapter (424121-8), Hex Wrench 3 (783201-2), Hook (346449-3)

  • DC motor and driving mechanism design provides long service life for maximum jobsite durability and performance
  • Reduced reaction force enables maximum operator control and reduced operator fatigue
  • Anti-dry fire mechanism prevents added wear on the drive pin
  • Easy to see, low profile contact tip for maximum fastening precision
  • Rubber bumpers protect tool and materials from damage
  • Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
  • LED battery capacity warning light indicates ideal time to recharge battery
  • LED job light illuminates work area
  • On-board depth control for quick and easy adjustment
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included: Tool Only. Batteries and Charger Sold Separately. Nose Adapter (424121-8), Hex Wrench 3 (783201-2), Hook (346449-3)

Shipping Dimensions (Length x Width x Height) & Weight : 11.61 In. X 14.41 In. X 4.37 In. Weight : 7.94 Lb.

Specifications

Battery Capacities: 18V LXT
Magazine Capacities 100 nails
Gauge 18 ga
Nail Length 5/8" - 2" (15 mm - 50 mm)
Vibration Level 2.5 m/s2
Noise Level 79 dB(A)
Dimensions (L x W x H) 11-5/8" x 3-13/16" x 12-1/2" (294 mm x 97 mm x 318 mm)
Net Weight 6.4 lbs (2.9 kg)
