DBN600Z

18V LXT 2-1/2" 16 ga Finish Nailer, Tool Only

Bump & Sequential Fire Operating Modes


LXT Technology 18V Battery
  • Anti-dry fire mechanism prevents added wear on the drive pin
  • Rubber bumpers protect tool and materials from damage
  • Quick release toolless nose enables easy clearing of jammed nails
  • Nail view window enables fast identification of remaining nail capacity
  • Trigger lock-off feature prevents accidental firing for increased operator safety
  • Compact center height for easy use when working in tight spaces and corners
  • Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
  • LED job light illuminates work area
  • On-board nail depth adjustment dial for quick and easy adjustment
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included:Tool Only. Batteries and Charger Sold Separately. Two Nose Adapters (424443-6), Hook (346449-3)

  • Anti-dry fire mechanism prevents added wear on the drive pin
  • Rubber bumpers protect tool and materials from damage
  • Quick release toolless nose enables easy clearing of jammed nails
  • Nail view window enables fast identification of remaining nail capacity
  • Trigger lock-off feature prevents accidental firing for increased operator safety
  • Compact center height for easy use when working in tight spaces and corners
  • Battery protection system provides over-discharge, temperature and current protection for enhanced performance, battery cycle life and overall battery life
  • LED job light illuminates work area
  • On-board nail depth adjustment dial for quick and easy adjustment
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included: Tool Only. Batteries and Charger Sold Separately. Two Nose Adapters (424443-6), Hook (346449-3)

Shipping Dimensions (Length x Width x Height) & Weight : 12.8 In. X 15.67 In. X 4.33 In. Weight : 9.04 Lb.

Specifications

Battery Capacities: 18V LXT
Magazine Capacities 100 nails
Gauge 16 ga
Nail Length 1" - 2-1/2" (25 mm - 64 mm)
Vibration Level 2.5 m/s2
Noise Level 89 dB(A)
Dimensions (L x W x H) 11-5/8" x 4-1/4" x 12-1/2" (296 mm x 108 mm x 318 mm)
Net Weight 6.9 lbs (3.1 kg)
