AN454

1-3/4" Coil Roofing Nailer

15° Round Head Coil Roofing Nailer


  • Improved trigger valve design provides quick nail driving in bump fire mode
  • Operates in bump fire & sequential fire mode
  • 6 depth nailing settings with adjustment knob for maximum precision
  • Tool-less shingle guide provides easy adjustments and consistent shingle placement
  • Nail path magnet prevents last nail from falling out
  • Convenient adjustable belt hook
  • One touch easy to load magazine
  • Easy to remove contact top to clear nail/debris jams
  • Rubberized grip for increased comfort during prolonged use

Items Included:Safety Goggles (HY00000394), Oil Supply (181434-7), Hex Wrench 4 (181434-7)

  • Improved trigger valve design provides quick nail driving in bump fire mode
  • Operates in bump fire & sequential fire mode
  • 6 depth nailing settings with adjustment knob for maximum precision
  • Tool-less shingle guide provides easy adjustments and consistent shingle placement
  • Nail path magnet prevents last nail from falling out
  • Convenient adjustable belt hook
  • One touch easy to load magazine
  • Easy to remove contact top to clear nail/debris jams
  • Rubberized grip for increased comfort during prolonged use

Items Included: Safety Goggles (HY00000394), Oil Supply (181434-7), Hex Wrench 4 (181434-7)

Shipping Dimensions (Length x Width x Height) & Weight : 13.19 In. X 13.39 In. X 5.12 In. Weight : 7.91 Lb.

Specifications

Operating Air Pressure 70 - 120 PSIG
Nail Size 3/4 – 1-3/4" (19 - 45 mm)
Nail Type 1/8" (3.0 mm) 15o Round Head
Magazine Capacity 120 nails
Vibration Level 5.7 m/s²
Noise Level 102 dB(A)
Dimensions (L x W x H) 10-1/8" x 4-5/8" x 10-5/8" (256 mm x 142 mm x 271 mm)
Net Weight 5.2 lbs (2.4 kg)
