DHS660ZB

18V LXT Brushless 6-1/2" Sub-Compact Circular Saw, Tool Only

SUB-COMPACT Size - PROFESSIONAL Power

Automatic torque Drive Technology (ADT), Lock-Off Button, Electric Brake, Soft Start, Blower, LED Light, Cutting Capacity of

LXT Technology LXT Technology Sub Compact LXT Technology ADT 18V Battery
  • Ultra-Compact and lightweight design with high performance for heavy-duty cutting applications
  • Brushless DC motor with high power to weight and size ratio
  • Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
  • Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
  • eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
  • Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
  • Soft start feature gradually increases speed to eliminate start up shock
  • Twin LED job light with pre-glow and afterglow features
  • Blower feature keeps cutting line free of sawdust
  • Trigger lock-off button prevents accidental start-up for increased safety
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included:Tool Only.  Battery and Charger Sold Separately. 6-1/2" C.T. Blade 24T (A-85092), Guide Rule (164095-8), Dust Nozzle Set (199230-9)

  • Ultra-Compact and lightweight design with high performance for heavy-duty cutting applications
  • Brushless DC motor with high power to weight and size ratio
  • Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
  • Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
  • eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
  • Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
  • Soft start feature gradually increases speed to eliminate start up shock
  • Twin LED job light with pre-glow and afterglow features
  • Blower feature keeps cutting line free of sawdust
  • Trigger lock-off button prevents accidental start-up for increased safety
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included: Tool Only.  Battery and Charger Sold Separately. 6-1/2" C.T. Blade 24T (A-85092), Guide Rule (164095-8), Dust Nozzle Set (199230-9)

Shipping Dimensions (Length x Width x Height) & Weight : 8.19 In. X 13.23 In. X 8.9 In. Weight : 7.94 Lb.

Specifications

Battery Capacities 18V LXT
Blade Diameter 6-1/2" (165 mm)
Arbor 5/8" (15.88 mm)
Max. Cutting Depth:
2-1/4" (57 mm)
45°  1-5/8" (41 mm)
50° 1-7/16" (37 mm)
No Load Speed 5,000 RPM
Vibration Level 2.5 m/s2
Noise Level 93 dB(A)
Overall Length 10-5/8" (270 mm)
Net Weight 5.6 lbs (2.5 kg)
