TW140DZ

3/8" Cordless Impact Wrench

Compact eXtreme Technology (CXT)

3/8" Square Drive, Variable Speed, Reversible

CXT Technology
  • Variable speed trigger allows operator to adjust fastening speed based on materials or application
  • Battery protection system provides over-discharge, temperature and circuit protection for enhanced performance, battery cycle life and overall battery life
  • LED job light with pre-glow and after-glow feature illuminates work area
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included:Tool Only. Batteries and Charger Sold Separately. Hook (346909-5)

  • Variable speed trigger allows operator to adjust fastening speed based on materials or application
  • Battery protection system provides over-discharge, temperature and circuit protection for enhanced performance, battery cycle life and overall battery life
  • LED job light with pre-glow and after-glow feature illuminates work area
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included: Tool Only. Batteries and Charger Sold Separately. Hook (346909-5)

Specifications

Battery Capacities 12V MAX Slide Li-ion
Square Drive 3/8"
No Load Speed 0 - 2,600 RPM
Impacts Per Minute 0 - 3,200 IPM
Maximum Fastening Torque  100 ft.lbs (140 Nm)
Vibration Level 8.0 m/s²
Noise Level 88 dB(A)
Overall Length 6-3/8" (161 mm)
Net Weight 1.8 lbs (0.8 kg)
