Makita General Catalogue

Electric

Power Tools

makita.ca

117

When

QUALITY & SERVICE

Counts – Choose Makita

STANDARD EQUIPMENT INCLUDES:

Side Handle (122727-3), Plastic Carrying Case (824737-3)

Makita’s Most POWERFUL Impact Wrench

• 1˝ Square drive, 738 ft. lbs (1,000 Nm)

• Side handle adjusts 360° for operator convenience at any angle

• Heavy duty front rubber bumper

• Rocker switch for easy one handed reversing

1˝ Impact Wrench

SPECIFICATIONS

Square Drive

1˝ Square

Capacities:

Standard Bolt 1˝ - 1-3/16˝ (24 - 30 mm)

High Tensile Bolt 7/8˝ - 1˝ (22 - 24 mm)

Impacts Per Minute

1,500 IPM

No Load Speed

1,400 RPM

Fastening Torque 738 ft. lbs (1,000 Nm)

AMPS (120V)

12.0 A

Overall Length

15.0˝ (382 mm)

Net Weight

19.0 lbs (8.6 kg)

TW1000

STANDARD EQUIPMENT INCLUDES:

Steel Carrying Case (182604-1), Side Handle (122464-9)

High Capacity Impact Wrench Ideal For Heavy Duty Industrial Applications

• High tech motor for heavy duty applications

• Rocker type reversing switch for easy one handed forward/reverse operation

• Side handle Adjusts 360° for operator convenience at any angle

• Heavy duty rubber bumper in front

Reversible

3/4˝ Impact Wrench

SPECIFICATIONS

Square Drive

3/4˝ Square

Capacities:

Bolt Size 5/8˝ - 7/8˝ (16 mm - 22 mm)

Impacts Per Minute

1,600 IPM

No Load Speed

1,500 RPM

Fastening Torque 433 ft. lbs (588 Nm)

AMPS (120V)

9.0 A

Overall Length

12-7/8˝ (327 mm)

Net Weight

12.3 lbs (5.6 kg)

6906

STANDARD EQUIPMENT INCLUDES:

Tool Only.

1/2˝ Square Drive

• Precision machined gears for long life and production usage

• Heavy duty front rubber bumper

• Rocker switch for easy one hande reversing

1/2˝ Impact Wrench

SPECIFICATIONS

Square Drive

1/2˝ Square

Capacities:

Bolt Size 1/2˝ - 3/4˝ (12 mm - 20 mm)

Impacts Per Minute

2,000 IPM

No Load Speed

1,700 RPM

Fastening Torque 217 ft. lbs (294 Nm)

AMPS (120V)

4.0 A

Overall Length

10-1/4˝ (270 mm)

Net Weight

6.2 lbs (2.8 kg)

6905B

STANDARD EQUIPMENT INCLUDES:

Plastic Carrying Case (824702-2)

High Power To Weight Ratio

• More power and torque than competitors 7.5 AMP models

• Heavy duty aluminum gear housing

• Heavy duty front rubber bumper

• Rocker switch for easy one handed reversing

• Ergonomic soft rubber grip for vibration absorption and comfortable operation

1/2˝ Impact Wrench

SPECIFICATIONS

Square Drive

1/2˝ Square

Capacities:

Standard Bolt 1/2˝ - 7/8˝ (12 - 22 mm)

High Tensile Bolt 1/2˝ - 5/8˝ (12 -16 mm)

Impacts Per Minute

2,000 IPM

No Load Speed

2,000 RPM

Fastening Torque 258 ft. lbs (350 Nm)

AMPS (120V)

3.5 A

Overall Length

11-1/8˝ (283 mm)

Net Weight

6.6 lbs (3.0 kg)

TW0350

STANDARD EQUIPMENT INCLUDES:

Belt Clip (324284-9), Plastic Carrying Case (824630-1)

Durable Lightweight 1/2˝ Drive Impact Wrench For Industrial Applications

• Heavy duty aluminum gear housing

• Rubber inlay grip reduces vibration

• Tool belt clip

• High power to weight ratio

• Variable speed allows user to have greater control

• Conveniently located forward/reverse switch

1/2˝ Impact Wrench

SPECIFICATIONS

Square Drive

1/2˝ Square

Capacities:

Standard Bolt

3/8˝ - 5/8˝ (10 - 16 mm)

High Tensile Bolt 5/16˝ - 1/2˝ (8 - 12 mm)

Impacts Per Minute

0 - 3,000 IPM

No Load Speed

0 - 3,000 RPM

Fastening Torque 111 ft. lbs (150 Nm)

AMPS (120V)

2.5 A

Overall Length

9-1/8˝ (233 mm)

Net Weight

3.3 lbs (1.5 kg)

6953

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

Phillips Bit 2-50(784244-7)

Multi-Purpose, Lightweight Impact Driver Can Be Used

For Any Light Fastening Applications

• Compact design and light weight (Only 8-5/8˝ and 2.1 lbs)

• Compact bit sleeve

• Easy to operate forward and reverse change lever

• Ergonomic soft rubber grip for vibration absorption and comfortable operation

Variable Speed, Reversible

1/4˝ Impact Driver

SPECIFICATIONS

Hex Shank

1/4˝ Hex

Impacts Per Minutes

0 - 3200 IPM

No Load Speed

0 - 3600 RPM

Maximum Torque 885 in.lbs (100 N.m)

Capacities:

Machine Screw M4 - M8 (5/32˝ - 5/16˝)

Standard Bolt M5 - M14 (3/16˝ - 9/16˝)

High Tensile Bolt M5 - M10 (3/16˝ - 3/8˝)

AMP (120V)

1.7 A

Overall Length

8-5/8˝ (218 mm)

Net Weight

2.1 lbs (0.96 kg)

TD0100

Reversible

Variable Speed,

Reversible
