60 / 180
BENCHTOP
makita.ca60
STANDARD EQUIPMENT INCLUDES:
14˝ Blade 70T(792699-2), Socket Wrench 13 (782212-4), Dust Bag (122330-0),Two Safety Switch Buttons (411478-6),
Horizontal Vise (122563-7)
Makita’s Largest Mitre Saw
• 2 Stage Safety Switch for increased operator safety
• Mitre Capacity of 45° Left or Right with Positive Stops at 0°, 15°, 22.5°, 30° and 45°
14˝ Mitre Saw
SPECIFICATIONS
Blade Diameter
14˝ (355 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
12.0 A
Overall Dimensions (L x W x H)
24˝ x 21˝ x 17-1/4˝
(610 mm x 530 mm x 440 mm)
Net Weight
75.4 lbs (34.2 kg)
LS1440
STANDARD EQUIPMENT INCLUDES:
12˝ C.T. Blade, Socket Wrench 13 (782212-4), Dust Bag (122852-0),Triangular Rule (762001-3), Vertical Vise (122540-9),
Two Safety Switch Buttons (416404-0),Two Holders (323726-0)
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
• Bevel Capacity of 45° Left
• Mitre Capacity of 45° Left or Right with Positive Stops at 0°, 15°, 22.5°, 31.6° and 45°
• Pivoting Fence (Left Side) can be adjusted when bevel cutting or to support larger materials
12˝ Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
12˝ (305 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
4,000 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
26-1/2˝ x 24˝ x 23-7/8˝
(674 mm x 610 mm x 607 mm)
Net Weight
37.0 lbs (16.8 kg)
LS1221
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 32T(721434-1), Socket Wrench 13 (782212-4), Dust Bag (122852-0), Vertical Vise (122536-0),Triangle Rule (762001-3),
Two Safety Switch Buttons (411478-6), Sub PlateAssy (193471-9)
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
• Bevel Capacity of 45° Left
• Mitre Capacity of 45° Left or 52° Right with Positive Stops at 0°, 15°, 22.5°, 30° and 45°
• Pivoting Fence (Left Side) can be adjusted when bevel cutting or to support larger materials
10˝ Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
4,600 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
20-7/8˝ x 18-3/4˝ x 21˝
(530 mm x 476 mm x 532 mm)
Net Weight
27.3 lbs (12.4 kg)
LS1040
STANDARD EQUIPMENT INCLUDES:
2705:
10˝ C.T. Blade 32T(A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5),
Hex Wrench 5 (783224-0),Adapter Ring 1" x 5/8" (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (125279-3)
2705X1:
Same as 2705 except with
Table Saw Stand
(194093-8)
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Smooth Operating Guide Rail with larger Locking Lever and Lock Mechanism for quick and easy setup
• Large cutting capacity (3-9/16˝ at 90° and 2-1/2˝ at 45°) allows cutting 4x material in a single pass
10˝ Table Saw & Table Saw with Stand
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16˝ (91 mm)
45°
2-1/2˝ (63 mm)
Maximum Dado Capacity
6˝ x 13/16˝ (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4˝ x 30-1/4˝
(678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
2705
2705X1
Riving Knife,
Electric Brake
Ideal For Trim And Flooring
Applications
• Sliding Rail Mechanism incorporating 4 Linear Ball
Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• Mitre Capacity of 47° Left or 57° Right with
Positive Stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel Capacity of 45° Left or 5° Right
7-1/2˝ Dual Sliding Compound Mitre Saws
SPECIFICATIONS
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
6,000 RPM
AMPS (120V)
10.0 A
Overall Dimensions (L x W x H)
17˝ x 26-3/8˝ x 18˝ (430 mm x 670 mm x 458 mm)
Net Weight
28.9 lbs (13.1 kg)
STANDARD EQUIPMENT INCLUDES:
7-1/2˝C.T.Blade40T(A-90629),HexWrench5 (783203-8),
TriangleRule(762001-3),
Dust Box
(194175-6),TwoSafetySwitches
Button(411478-6),VerticalVise(122571-8),TwoHolders(322312-4)
LS0714B
STANDARD EQUIPMENT INCLUDES:
8-1/2˝ C.T. Blade 48T(A-95934), Box Wrench 13-3 (JM23100197), Dust Bag (JM23510010), Vertical Vise (JM23510009),
Triangle Rule (JM27000328),Two Holders (JM23000127)
Up To 12˝ Cuts In 2x Material
• Electric brake for increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• LED job light illuminates cutting area for increased accuracy and precision
• Factory calibrated class II laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 48° left or 5° right
• Mitre Capacity of 50° left or 60° right with positive stops at 0°, 15°, 22.5°, 31.6° and 45°
• 2 stage safety switch for increased operator safety
8-1/2
˝
Sliding Compound Mitre Saw with Laser and LED Light
SPECIFICATIONS
Blade Diameter
8-1/2˝ (216 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
5,000 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
29-1/2˝ x 17-3/4˝ x 19˝
(750 mm x 450 mm x 483 mm)
Net Weight
31.1 lbs (14.1 kg)
LS0815FL
High Cutting Capacity And Dust Extraction Rate
STANDARD EQUIPMENT INCLUDES:
7-1/2˝C.T.Blade40T(A-90629),HexWrench5(783203-8),
TriangleRule(762001-3),
Dust Bag
(122852-0),TwoSafetySwitches
Button(411478-6),VerticalVise(122571-8),TwoHolders(322312-4)
LS0714
