67 / 180
Electric
Power Tools
makita.ca67
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
5˝ Continuous Rim Diamond Wheel (A-90934), Hex Wrench 5 (783203-8), Wrench 22 (781011-1), Wrench Holder 5.6 (410047-0),
Water Supply Plug (165263-6), Pressure Regulator (165264-4)
Ideal For Wet Cutting Of Tile, Masonry, Concrete And More
• Special Cover Design prevents water from entering motor housing
• Equipped with a Ground Fault Circuit Interrupter (GFCI) plug for operator safety
• Lock-On Button for easy continuous operation
• Bevel Capacity of 45°
• Includes 15 ft. of Tubing, Water Pressure Regulator and Water Valve
Blade Left
5˝ Masonry Saw
SPECIFICATIONS
Blade Diameter
5˝ (125 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacities:
0°
1-5/8˝ (41.5 mm)
45°
1˝ (26 mm)
No Load Speed
13,800 RPM
AMPS (120V)
7.9 A
Overall Length
9-1/4˝ (236 mm)
Net Weight
6.5 lbs (3.0 kg)
4101RH
STANDARD EQUIPMENT INCLUDES:
4"Turbo Rim Diamond Blade (A-94546), 4-3/8" Curved Diamond Blade (D-36968), Wrench 22 (781041-2), Hex. Wrench 5 (783217-7)
Dry Cutting Masonry Saw For Stone, Masonry, Tile, Concrete And More
• Wide Blade Case enables use of Curved Diamond Wheel
• Heavy Duty Aluminum Gear Housing for increased durability
• 14 ga Steel Baseplate ensures accuracy and durability
• Leading Edge of Baseplate indicates precise line of cut
• Dust Proof Switch and Labyrinth Construction prevents contamination of motor
• Flat Motor Housing allows tool to stand upright when changing blades
• Bevel Capacity of 45°
4-3/8˝ Masonry Saw
SPECIFICATIONS
Blade Diameter
5˝ (120 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacities:
0°
1-1/4˝ (32.5 mm)
45°
7/8˝ (21.5 mm)
No Load Speed
12,200 RPM
AMPS (120V)
10.0 A
Overall Length
9-3/8˝ (238 mm)
Net Weight
6.4 lbs (2.9 kg)
4100NH2ZX1
Blade Left
Unique Plunge Action For Specialized Cuts
• Depth Stopper enables splinter-free cutting
• PrecisionBevelCutfeaturemaintainsexactbladepositionforquickandeasybevelcutting
withoutcompensatingadjustments
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Overload Protection prevents motor burnout due to current overload
• Variable Speed Dial adjusts cutting speed based on materials or application
• Close to Wall Cut of just 11/16˝
SPECIFICATIONS
Blade Diameter
6-1/2˝ (165 mm)
Arbor
13/16˝ (20 mm)
Maximum Cutting Capacity:
0°
2-3/16˝ (56 mm)
45°
1-9/16˝ (39 mm)
48°
1-1/2˝ (38 mm)
No Load Speed
2,000 - 6,400 RPM
AMPS (120V)
12.0 A
Overall Length
13-3/8˝ (341 mm)
Net Weight
9.7 lbs (4.4 kg)
55˝ Guide Rail
(139.7 cm)
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353),
Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013),
55˝ (139.7 cm) Guide Rail (194368-5)
SP6000X1
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353),
Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013),
118˝ (299.7 cm) Guide Rail (194367-7)
SP6000X2
+
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353), Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013)
SP6000
+
+
SP6000, SP6000X1, SP6000X2
6-1/2
˝
Plunge Cut Circular Saws
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Two 5˝ Diamond Wheels, D-Style Front Handle (417665-5), Lock Nut Wrench 35 (782407-9), Hex Wrench 6 (783204-6),
InterlockingTool Case (197213-3)
Cuts Two Parallel Lines In Concrete Or Masonry To Enable Recessing Of
Conduit Pipe, Wiring And More!
• "SJS" (Super-Joint System) prevents kickback during wheel lock-up for optimal tool and operator protection
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Electronic current limiter prevents motor burnout due to overloading
• 360° rotatable dust extraction port
• Adjustable depth scale enables fast and accurate depth setting
"SJS" Technology,
Electronic Current
Limiter, Soft Start,
Constant Speed
Control
5˝ Wall Chaser
SPECIFICATIONS
Blade Diameter
5˝ (125 mm)
Arbor
7/8˝ (22.23 mm)
Blade Thickness
5/64˝ (2.1 mm)
Cutting Depth
0 - 1-3/16˝ (0 - 30 mm)
Cutting Width
Every 1/8˝ from 1/8˝ to 1-3/16˝
(Every 3 mm from 6 to 30 mm)
No Load Speed
10,000 RPM
AMPS (120V)
12.0 A
Overall Length
13-3/4˝ (350 mm)
Net Weight
9.9 lbs (4.5 kg)
SG1251J
118˝ Guide Rail
(299.7 cm)
STANDARD EQUIPMENT INCLUDES:
4"Turbo Rim Diamond Blade (A-94546), Wrench 22 (781041-2), Hex. Wrench 5 (783217-7)
Dry Cutting Masonry Saw For Stone, Masonry, Tile, Concrete And More
• Wide blade case enables use of curved diamond wheels
• Heavy duty aluminum gear housing for increased durability
• 14 ga steel baseplate ensures accuracy and durability
• Leading edge of baseplate indicates precise line of cut
• Dust proof switch and labyrinth construction prevents contamination of motor
• Flat motor housing allows tool to stand upright when changing blades
4-3/8˝ Masonry Saw
SPECIFICATIONS
Blade Diameter
4-3/8˝ (110 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacity:
0°
1-1/4˝ (32 mm)
No Load Speed
13,000 RPM
Amps (120V)
9.5 A
Overall Length
8-15/16˝ (227 mm)
Net Weight
6.4 lbs (2.9 kg)
4100NH3ZX
Blade Left
