Makita General Catalogue

Electric

Power Tools

makita.ca

103

STANDARD EQUIPMENT INCLUDES:

Paper Filter Bag (1 Ea. P-70194), Plastic Disposal Bag (1 Ea. P-70297), PETFleece Filter Element (P-70219),

1˝ (I.D.) x 11-1/2'Anti-Static Suction Hose (P-70487)

Push & Clean Filter System clears particulate and debris from clogged

filters to maximize filter efficiency and maintain suction power

• Onboard Outlet andAutomatic Start Feature enables dust extractor to be operated in conjunction

with power tools

• Variable Settings enables operator to adjust the suction power to the application

Portable,

Efficient Dust

Extraction

Technology

L Class Push & Clean Filter Cleaning Dust Extractor (7 Gallon)

SPECIFICATIONS

Container Capacity

27 L (7 Gal)

Dry Tank Capacity

27 L (7 Gal)

Wet Tank Capacity

27 L (7 Gal)

Maximum Air Flow

113 CFM

Standard Filter Particulate Rating

1 micron

Static Water Lift

93˝ (235 cm)

AMPS (120V)

8.7 A

Power Cord Length

25´ (7.5 m)

Overall Length

15-1/2˝ (39 cm)

Net Weight

24.0 lbs (10.9 kg)

446L

STANDARD EQUIPMENT INCLUDES:

Dust Bag (1 Ea. P-78293), Plastic Disposal Bag (1 Ea. P-70297),

Flat Filter Element (1 Ea. P-79843),Anti-Static Hose 1-3/8˝ (P-79865), Crevice Nozzle (P-80005)

Xtract Vac

Automatic Filter Cleaning System clears filter at regular

intervals to maximize filter efficiency and maintain suction power

• Rocker Valve isolates each filter during cleaning process to prevent interruption of suction power

• Onboard Outlet and Automatic Start Feature enables dust extractor to be operated in conjunction

with power tools

L Class Automatic Filter Cleaning Dust Extractor (12 Gallon)

SPECIFICATIONS

Container Capacity

45.4 L (12 Gal)

Dry Tank Capacity

34.0 L (9 Gal)

Wet Tank Capacity

30.2 L (8 Gal)

Maximum Air Flow

135 CFM

Standard Filter Particulate Rating

2 microns

Static Water Lift

92˝ (233 cm)

AMPS (120V)

12.0 A

Power Cord Length

26.25´ (8 m)

Overall Length

29-1/2˝ (75 cm)

Net Weight

27.0 lbs (12.3 kg)

VC4710

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Portable, Efficient

Dust Extraction Technology

DUST EXTRACTOR ACCESSORIES

Part No.

Description

Application

For Models

Filter Accessories

P-79843

Nano Fleece Filter Element (2 / Pk)

99.95% Efficiency (0.05% Max. Permeability) ≥ 2 microns (µ)

VC4710

P-79859

HEPA™ Filter Element (2 / Pk)

99.97% Efficiency (0.03% Max. Permeability) ≥ 0.3 microns (µ)

P-70219

PET Fleece Filter Cartridge

99.97% Efficiency (0.03% Maximum Permeability) ≥ 1 micron (µ)

446L

T-01806

HEPA™ Filter Cartridge

99.995% - 99.999% Efficiency (0.005% - 0.001% Maximum Permeability) ≥ 0.3 micron (µ)

P-80002

Filter Screen

Replaces filter when vacuuming wet materials

P-80001

Exhaust Fitting

Enables set up of dust free environment with 1-3/8" A/S Suction Hose

Filter & Disposal Bags

P-78293

Nano Fleece Filter Bags (5 / Pk)

Lock Out Nano Fleece Filter Bags for dry material

VC4710

P-70297

Plastic Disposal Bags (5 / Pk)

Disposal bags for semi-wet material or liners with Fleece Filter Bags

VC4710, 446L

P-70194

Paper Filter Bags (5 / Pk)

Lock Out Paper Filter Bags for dry material

446L

Anti-Static Suction Hoses

P-70487

1" I.D. Anti-Static Suction Hose

1" I.D. x 11-1/2' Length

VC4710

446L

P-79865

1-3/8" I.D. Anti-Static Suction Hose

1-3/8" I.D. x 9-1/2' Length / Features P-70421 1-3/8" Hose Joint

P-70362

1-3/8" I.D. x 9-1/2' Length / Features Quick Connect Coupling

Dust Extraction / Vacuum Accessories

P-70384

Quick Connect Coupling

Quick Connect Coupling for 1-3/8" A/S Suction Hose

VC4710

446L

P-70378

Quick Connect Tool Adapter

Quick Connect Tool Adapter for 1-3/8" A/S Suction Hose

P-80003

Holders (2 / Pk)

Attaches to 446L Dust Extractor for Power Cord Storage

P-80004

Square Brush Nozzle

For vacuuming tasks / 1-3/4" x 2-3/4" Brush Size

P-80005

Crevice Nozzle

For vacuuming tasks in narrow areas / 12" length

P-70471

Rectangular Brush Nozzle

For vacuuming tasks / 1-3/4" x 5" Brush Size

P-70465

Floor Nozzle

For vacuuming floors with Hard or Soft surfaces

P-72942

Extension Tubes

2 x 20-1/2" lengths / 39-1/2" assembled length

P-70346

Curved Tube Handle

Handle for use with Extension Tubes

P-70502

Brush & Nozzle Set 1 (4 pcs)

Includes: Crevice Nozzle + Brush, Rectangular Brush Nozzle, Universal Nozzle

P-70518

Brush & Nozzle Set 2 (3 pcs)

Includes: Square Brush Nozzle, Universal Nozzle, Rubber Tube Nozzle

P-70312

Brush & Nozzle Set 3 (8 pcs)

Includes: Floor Nozzle, Square Brush Nozzle, Universal Nozzle, Crevice Nozzle, Pipe Holder,

19" Extension Tubes (2 pcs), Curved Tube Handle

Brush & Nozzle Set

Plastic Disposal Bags

Paper Filter Bags

HEPA Filter

Cartridge

PET Fleece

Filter Cartridge
