Makita General Catalogue

Electric

Power Tools

makita.ca

STANDARD EQUIPMENT INCLUDES:

1-1/8˝ Hex Shank Bull Point (751420-A), Plastic Carrying Case (824897-1)

1-1/8˝ Hex Shank

• Anti-Vibration Technology (AVT

) actively

counteracts vibration of tool for greatly reduced

transmission to operator

• Constant Speed Control maintains constant

speed under heavy load

• Soft Start feature gradually increases speed to

eliminate start up shock

• Variable Speed Dial allows operator to adjust

speed based on materials or application

• No-Load Motor Suppression limits vibration

and bit deflection when idling

Constant Speed Control,

Variable Speed,

Soft Start

42 lbs Demolition Hammer

SPECIFICATIONS

Bit Type

1-1/8˝ Hex

Blows Per Minute

730 - 1,450 BPM

Impact Energy

33.8 J (24.9 ft. lbs)

AMPS (120V)

14.0 A

Overall Length

32-1/2˝ (824 mm)

Net Weight

41.9 lbs (19.0 kg)

HM1317CB

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

HM1812:

Hex wrench (783203-8), 1-1/8˝Hex Shank Bull Point (B-45559)

HM1812X1:

1-1/8˝HexShankBullPoint(B-45559),1-1/8˝HexShankNarrowChisel(751220-A),HexWrench5(783203-8),HammerCart(T-02892)

1-1/8˝ Hex Shank

• Increased impact energy (72.8 J) for maximum demolition power. HIGHEST IMPACT ENERGY IN CLASS

• NEW Anti-Vibration Technology

(AVT

) offers LOWEST VIBRATION IN CLASS

• Soft start feature gradually increases speed to eliminate start up shock

• No load motor suppression limits vibration and bit deflection when idling

• Use with Dust Extraction Attachment (part no. 197172-1) for dust-free operation

70 lbs Breaker Hammers

HM1812 HM1812X1

197172-1

Highest Impact

Energy Rating (72.8 J)

In-Class!

HM1812

SPECIFICATIONS

Bit Type

1-1/8˝ Hex

Blows Per Minute

870 BPM

Impact Energy

72.8 J (53.7 ft. lbs)

AMPS (120V)

15.0 A

Overall Length

33-1/4˝ (843 mm)

Net Weight

69.1 lbs (31.3 kg)

Maximizing Power

and User Comfort

while Controlling

Harmful Vibration

Makita’s dynamic vibration absorbing system

By using the inverse relationship of air pressure between the crankcase and piston cylinder,

the balancer moves in the opposite direction of the piston to minimize vibration.

Balancer

Piston

Air

Vibration absorption grip for maximum control

Utilized on the following models: HR3210FC,

HR3210FCT, HR4011C,HR4511C, HR5211C

Spring loaded hinged grip absorbs vibration

Spring

Hinge

Protect Your

Investment in Tools & People

HM1812

HR4013C

HM1812X1

STANDARD EQUIPMENT INCLUDES:

SDS-MaxBullPoint(751423-A),BitGrease(194683-7),CleaningCloth(443122-7),D-StyleSideHandle(135269-8),PlasticCarryingCase(824908-2)

SDS-MAX Shank

• Anti-Vibration Technology (AVT

) actively counteracts vibration of tool for greatly reduced

transmission to operator

• Constant Speed Control maintains constant speed under heavy load

• Soft Start feature gradually increases speed to eliminate start up shock

• Variable Speed Dial allows operator to adjust speed based on materials or application

• No-Load Motor Suppression limits vibration and bit deflection when idling

• Auto-Shut Off Carbon Brushes shut off motor when carbon brushes require replacement

• Slide Style On / Off Switch for easy continuous use applications

• 12 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• One-Touch Sliding Chuck for easy bit installation and removal

• LED Service Light indicates appropriate time to change carbon brushes

Constant Speed Control,

Variable Speed, Soft Start

23.8 lbs Demolition Hammer

SPECIFICATIONS

Bit Type

SDS-MAX

Blows Per Minute 950 - 1,900 BPM

Impact Energy 25.5 J (18.8 ft. lbs.)

AMPS (120V)

14.0 A

Overall Length

22-3/4˝ (576 mm)

Net Weight

23.8 lbs (10.8 kg)

HM1213C
