8 / 32
6
UPRIGHT
VACUUM
The DVC560 will be the first 18V LXTUpright Vacuum to provide both a rotating power
brush for deep carpet cleaning and a detachable hand-wand for detail cleaning with
the onboard accessories
HIGH DUST
PICK-UP RATE
4 rows of V-shaped bristle increase
dust pick-up rate.
Suction power is even across the
entire cleaning width due to the
suction port located at the center.
TWO
DIFFERENT
BRUSHLESS
MOTORS
• One for vacuuming dust and the
other for rotating brushroll
• Two motors are separately
controlled according to the
selected suction mode
Suction Port
DVC560 UPRIGHT VACUUM ACCESSORIES
Part Number
Description Application /
Specification
For
Model
Part Number
Description Application /
Specification
For
Model
191E39-5
HEPA Filter
99.97% Efficiency (0.03%
Maximum Permeability)
≥ 1 Micron (µ)
DVC560
191D67-4
Round
Brush
Extraction For
Fine Detail Work DVC560
191D63-2
(10 / Pk)
Filter
Bag Set
Filtration For
Dry Material
DVC560
191D65-8
Long Sash
Nozzle
Extraction For
Fine Detail Work DVC560
191D69-0
Brush Set
Capture Large
Debris And Small
Particles
DVC560
DVC560
Model No.
DVC560
Model Name
18Vx2 LXT 5.0 L Upright Vacuum Cleaner
Battery Capacities
Two 18V Li-Ion
Container Capacity
5.0 L
Continuous use
with Two 18V Li-Ion
Batteries
Approx. 25 minutes (Max) / 50 minutes (Normal)
100 minutes (Low Noise)
with Two 18V (5.0 Ah) Li-Ion Batteries
Maximum Air Flow
67 CFM
Power
85 W (Max) / 50 W (Normal) / 25 W (Low Noise)
Static Water Lift
48.2" (122 cm)
Noise Level
70 dB(A)
Overall Length
12-7/8" (326 mm)
Net Weight
19.9 lbs (9 kg)
Available as
DVC560PT2 / DVC560Z
Model No.
Description
Includes
DVC560PT2
18Vx2 (5.0 Ah) LXT 5.0 L
Upright Vacuum Cleaner Kit
Two 18V (5.0 Ah) Li-Ion Batteries (196675-2), Dual Port Rapid Charger (DC18RD),
HEPA Filter (191E39-5),
1-1/8" x 2.3' Hose (140S37-0), 1-1/8" x 0.6' Hose (140S36-2), Paper Filter Bag ( 1 Ea. 191D63-2), Corner Nozzle (191D65-8),
Round Brush (191D67-4)
DVC560Z
18Vx2 LXT 5.0 L
Upright Vacuum Cleaner (Tool Only)
Tool Only. Batteries and Charger Sold Separately.
HEPA Filter (191E39-5), 1-1/8" x 2.3' Hose (140S37-0), 1-1/8" x 0.6' Hose (140S36-2),
Paper Filter Bag ( 1 Ea. 191D63-2), Corner Nozzle (191D65-8), Round Brush (191D67-4)
