76 / 220
Cordless
Power Tool Accessories
makita.ca
74
CORDLESS CAULKINGGUNCONVERSIONKITS
Conversion kits allow operators to quickly and easily adapt their cordless caulking
gun to 300 ml, 600 ml or 800 ml capacities
Part No.
Description
Includes
196351-8
• 300 ml
Holder Kit
• For Models
CG100DZB / C
DCG180RFEB /
ZB / ZC
• Tray
• Tray Collars
• Piston
• Plunger
• Use with Plate 346649-5
when converting from
800 ml models
196352-6
• 600 ml
Holder Kit
• For Models
CG100DZA / C
DCG180RFE /
Z / ZC
• Tube
• Tube Collars
• Plunger
• Piston (3 ea.)
• Nozzle (3 ea.)
• Use with Plate 346649-5
when converting from
800 ml models
197195-9
• 800 ml
Holder Kit
• For Models
CG100DZA / B
DCG180RFE /
RFEB / Z / ZB
• Tray
• Tray Collars
• Piston
• Plunger
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
FINDERDRIVERS
Description
Includes
Finder –Driver
784810-A
• Outer sleeve surrounds both bit tip and screw head
• Keeps bit tip in screw head
• Prevents screws from wobbling
• Sleeve retracts as screw penetrates wood
• Overall length: 4-5/8" (without insert bit)
• Retracting
Screw Holder
• #2 Phillips bit
• #2 Robertson
insert bit
Contractor Finder –Driver
784812-A
• Large diameter for holding #12 screws
• Overall length: 4-5/8" (without insert bit)
• Retracting
Screw Holder
• 1/4" nutsetter
• #2 Phillips bit
Finder –Driver Duo Set
784810-A-A
Retracting Screw Holder contains a convenient
Stubby
Finder / Driver™ for most screws and the original
Finder / Driver™ for long screws
• #1 Phillips bit
• #6-8 slotted
insert bits
• 1/4'' nutsetter
• 2 ea. #2
Phillips bit
Stubby Finder –Driver
784811-A
• Shortened model for access into tighter work spaces
• Gives excellent control when starting screws
• Overall length: 3-1/8" (without insert bit)
• Retracting
Screw Holder
• #2 Phillips bit
• #2 Robertson
insert bit
Shorty Finder –Driver
784867-A
• A compact size for tight places
• Overall length: 2-1/4" (without insert bit)
• Retracting
Screw Holder
• #2 Phillips bit
Quad Flip-Driver
784818-A
• Reversible Double-Ended Driver Assembly
• Quad driver
• #2 Phillips
square
drive bit
COMPACT BANDSAWBLADE COVER
197222-2
Description
• Prevents materials and debris from entering blade casing
• Shields operator from blade for maximum jobsite safety
• Quick and easy installation • Includes 2 ea. hinges and clips
• For models: DPB181
LASER
DISTANCE
MEASURERS
• Accuracy & Consistency
• Speed
• Versatility & Simplicity
LD030P
LD050P
LD080PI
Accuracy
5/64"
5/64"
1/64"
Operating Range
98'
164'
262'
Laser Class
II (<1 mW) @ 635 nM
Power Supply
Two AAA Batteries
Battery Life
Up to 5,000
Measurements
Up to 3,000
Measurements
Up to 5,000
Measurements
Measuring Units
4
6
7
Auto Power / Laser Off
Yes
Adapts to Tripod
No
No
Yes
Reference Points
2
2
5
Continuous
Yes
No
Yes
Stake-Out
No
No
Yes
Distance
Yes
Tilt
No
No
Yes
Area
Yes
Volume
No
Yes
Yes
Minimum / Maximum
No
Yes
Yes
Add / Subtract
No
Yes
Yes
Pythagoras (Partial / 2 / 3)
No
No / Yes / Yes
Yes / Yes / Yes
Smart Horizontal
No
No
Yes
Height Tracking
No
No
Yes
Levelling
No
No
Yes
Timer
No
No
Yes
Memory
No
Last 5
Measurements
Last 20
Measurements
Band SawBlade CuttingWax
191897-9
Reduces Heat Build-up and Increases Cutting
Performance of Band Saw Blades
