GA6020C

6" Angle Grinder w/SJS, Electric Control & Trigger Switch

Trigger Switch with Lock-On Button (AC)

"SJS" Technology, Electronic Current Limiter, Constant Speed Control, Soft Start

SJS Technology
  • SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
  • Electronic current limiter prevents motor burnout due to overloading
  • Soft start feature gradually increases speed to eliminate start up shock
  • Constant speed control maintains constant speed under heavy load
  • Anti-Restart feature prevents accidental start up of tool if switch is locked in the on position
  • LED Light indicates active power supply and activation of anti-restart feature
  • Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
  • Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
  • Rotatable gear housing can be positioned at every 90o for optimal positioning
  • Removable side handle can be mounted on left or right side of tool
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included:Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224361-6), Lock Nut 5/8-45(224568-4), Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel (1 Ea. A-95978-25)

  • SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
  • Electronic current limiter prevents motor burnout due to overloading
  • Soft start feature gradually increases speed to eliminate start up shock
  • Constant speed control maintains constant speed under heavy load
  • Anti-Restart feature prevents accidental start up of tool if switch is locked in the on position
  • LED Light indicates active power supply and activation of anti-restart feature
  • Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
  • Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
  • Rotatable gear housing can be positioned at every 90o for optimal positioning
  • Removable side handle can be mounted on left or right side of tool
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Items Included: Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224361-6), Lock Nut 5/8-45(224568-4), Toolless Wheel Cover (123146-6), 6" Depressed Center Wheel (1 Ea. A-95978-25)

Shipping Dimensions (Length x Width x Height) & Weight : 5.12 In. X 18.43 In. X 6.1 In. Weight : 9.04 Lb.

Specifications

Maximum Capacities:
Wheel 6" (150 mm)
Sanding Disc 6" (150 mm)
Wire Cup Brush 3-1/2" (90 mm)
Spindle Thread 5/8" - 11 UNC
No Load Speed: 9,000 RPM
AMPS (120V) 12.5 A
Vibration Level 9.0 m/s2
Noise Level 91 dB(A)
Overall Length 15-3/8" (390 mm)
Net Weight 6.6 lbs (3.0 kg)
