5" Angle Grinder

Thumb Switch with Lock-On (AC/DC)

Labyrinth construction seals motor and bearings from contamination
Thumb switch conveniently located for operator comfort
Removable side handle can be mounted on left or right side of tool

Where to buy

Items Included:5” Depressed Center Wheel (1 Ea. A-95962-25), Wheel Cover (123734-9), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4), Side Handle (153489-2)

782424-9

224399-1

224568-4

Images shown may not represent the full listing or the true size of included items.

Labyrinth construction seals motor and bearings from contamination
Thumb switch conveniently located for operator comfort
Removable side handle can be mounted on left or right side of tool

Items Included: 5” Depressed Center Wheel (1 Ea. A-95962-25), Wheel Cover (123734-9), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4), Side Handle (153489-2)

Shipping Dimensions (Length x Width x Height) & Weight : 13.66 In. X 5.63 In. X 4.76 In. Weight : 6.39 Lb.

Specifications

Maximum Capacities:
Grinding Wheel	5" (125 mm)
Sanding Disc	5" (125 mm)
Wire Cup Brush	3-1/2" (90 mm)
Spindle Thread	5/8" - 11 UNC
No Load Speed	11,000 RPM
AMPS (120V)	7.5 A
Vibration Level	8.5 m/s²
Noise Level	86 dB(A)
Overall Length	10-5/8" (271 mm)
Net Weight	4.6 lbs (2.1 kg)
