METALWORKING
makita.ca142
SJS (Super Joint System) prevents kickback
during wheel lock up for optimal tool and operator protection
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Variable speed dial allows operator to adjust speed based on materials or application
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features "zig-zag" varnish on the armature and hardened
powder on the field coils to act as an impenetrable barrier to dust and debris
• Standard equipment side handle provides maximum operator control
during operation
SPECIFICATIONS
Collet Capacity
1/4˝ (6.4 mm)
GD0800C:
Maximum Wheel Point Diameter 1˝ (25 mm)
GD0800C:
No Load Speed
7,000 - 29,000 RPM
GD0810C:
Maximum Wheel Point Diameter 2˝ (50 mm)
GD0810C:
No Load Speed
1,800 - 7,000 RPM
AMPS (120V)
6.6 A
Overall Length
14-5/8˝ (371 mm)
Net Weight
3.7 lbs (1.7 kg)
High Speed Range
STANDARD EQUIPMENT INCLUDES:
Collet Cone Set 1/4˝ (192986-3), Wrench 13 (781203-2), Wrench 19 (781206-6),
Side Handle (192985-5) shown with optional accessory
GD0800C
STANDARD EQUIPMENT INCLUDES:
Collet Cone Set 1/4˝ (192986-3), Wrench 13 (781203-2), Wrench 19 (781206-6),
Side Handle (192985-5) shown with optional accessory
GD0810C
Light Weight And Slim Housing For Easy Handling
• Conveniently located thumb switch for operator comfort (GD0601 Only)
• Large paddle switch with lock-off feature (GD0600 Only)
• Protective Zig-Zag varnish seals the motor from dust and debris for longer life
• Round-shaped collet nut reduces the possibility of damage or scratches to workpiece
• High heat resistance
• Vent Slots designed to direct air exhaust away from the user
• AC/DC switch for use with alternative power source
Anti-Slip Rubber Cover, AC/DC
SPECIFICATIONS
Collet Capacity
1/4˝ (6.4 mm)
Maximum Wheel Point Diameter 1-1/2˝ (38 mm)
No Load Speed
25,000 RPM
AMPS (120V)
3.5 A
Overall Length
14-1/8˝ (359 mm)
Net Weight
3.7 lbs (1.7 kg)
Thumb Switch
Paddle Switch
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763625-8),Two Wrenches 13 (781039-9)
GD0601
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763625-8),Two Wrenches 13 (781039-9)
GD0600
GD0800C, GD0810C
1/4˝ Die Grinders
GD0601, GD0600
1/4˝ Die Grinders
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Low Speed Range
Makita offers a wide variety of
ACCESSORIES!
DIE GRINDER ACCESSORIES
Part No.
Description
For Model(s)
763625-8
1/4" Collet Cone
GD0603, GD0601, GD0600, 906
763626-6
1/8" Collet Cone
763664-8
Collet Nut
GD0601, GD0600, GD0603
763606-2
Collet Nut
GD0603, 906
763672-9
1/8" Collet Cone
DGD800
763673-7
1/4" Collet Cone
763668-0
Collet Nut
192986-3
1/4" Collet Cone / Nut Set
GD0800C, GD0810C
192987-1
1/8" Collet Cone / Nut Set
763645-2
Collet Nut
741616-9
1/4" Cone Wheel Point
GD0603, GD0600, GD0601, GD0800C GD0810C, DGD800, 906
741617-7
1/4" Flat Wheel Point
Collet
Cone
Flat
Wheel Point
Cone
Wheel Point
Collet
Nut
