Makita General Catalogue

METALWORKING

makita.ca

144

STANDARD EQUIPMENT INCLUDES:

Blade Set (135168-4), Shear Head (125354-5), Hex Wrench 5/32˝ (783221-6), Plastic Carrying Case (824780-2)

• Pistol grip design for increased operator comfort and control

• Lightweight cast aluminum gear housing for optimal jobsite durability

• Easily accessible carbon brushes for quick replacement on the jobsite

• Retractable belt clip for operator convenience

• Lock-On button enables comfortable continuous operation during periods of prolonged use

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Variable Speed Trigger Switch For

Controlled Cutting

Fibre Cement Board Shear

SPECIFICATIONS

Max. Capacity:

Cement

5/16˝ (8 mm)

AMPS (120V)

6.5 A

Strokes Per Minute

0 - 2,500 SPM

Overall Length

13-5/8˝ (346 mm)

Net Weight

4.9 lbs (2.2 kg)

JS8000

STANDARD EQUIPMENT INCLUDES:

Hex Wrench 5/32˝ (783215-1), Shear HeadAssembly (125849-8)

• Pistol grip design for comfort and convenience

• Lightweight cast aluminum gear housing for durability

• Retractable belt clip for operator convenience

• Lock-on button for easy continuous operation

• Shear head attachment rotates 360°

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Variable Speed Trigger Switch For

Controlled Cutting Speed

18 ga Straight Shear

SPECIFICATIONS

Maximum Capacities:

Steel

18 ga. (1.3 mm)

Stainless

20 ga. (1.0 mm)

AMPS (120V)

6.5 A

Strokes Per Minute

0 - 2,500 SPM

Overall Length

11-7/8˝ (302 mm)

Net Weight

4.0 lbs (1.8 kg)

JS1300

STANDARD EQUIPMENT INCLUDES:

HexWrench3(783201-2),WrenchHolder3.4(410048-8),ShearBladeSet(191383-0)

Fast Cutting Action In Steel And Aluminum With Increased Comfort,

Maneuverability And Control

• Built-in thickness gauge for operator convenience

• Sliding On / Off thumb switch

• 360

rotatable shear head

• Small circumference, ergonomic motor housing for increased comfort, maneuverability and control

16 ga Straight Shear

SPECIFICATIONS

Maximum Capacities:

Steel

16 ga. (1.6 mm)

Aluminum

13 ga. (2.5 mm)

AMPS (120V)

3.3 A

Strokes Per Minute

4,000 SPM

Minimum Cutting Radius 1-3/16˝ (30 mm)

Overall Length

10˝ (255 mm)

Net Weight

3.4 lbs (1.6 kg)

JS1602

STANDARD EQUIPMENT INCLUDES:

Shear Blade Set (792287-5), Gauge (762007-1), Hex Wrench 4 (783202-0), InterlockingTool Case (197211-7)

For Heavy Duty Cutting In Up To 10 Gauge Mild Steel

• Cuts with no material loss in the kerf as with nibblers

• Replaceable blades offer 4 cutting edges for maximum precision

• Built-in thickness gauge for operator convenience

• Highly visible sight line for precise following of patterns

• Scrap Guide protects tool and operator from sheared material

10 ga Shear

SPECIFICATIONS

Maximum Capacities:

Steel

10 ga. (3.2 mm)

Aluminum

9 ga. (4.0 mm)

AMPS (120V)

6.2 A

Strokes Per Minute

1,600 SPM

Minimum Cutting Radius

2˝ (50 mm)

Overall Length

8-3/8˝ (213 mm)

Net Weight

7.4 lbs (3.4 kg)

JS3201J

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

JS1000:

Side Blade Set (792536-0), Center Blade (792537-8), Hex Wrench 3 (783201-2)

JS1601:

Side Blade Set (792533-6), Center Blade (792534-4), Gauge (762013-6), Hex Wrench 3 (783201-2)

Fast Cutting Action In Steel And

Aluminum With Increased Comfort,

Maneuverability And Control

• JS1000 - Minimum outside cutting radius of just 9-7/8˝

• JS1601 - Minimum outside cutting radius of just 1-3/16˝

• Ribbed motor housing and rear cover for improved

gripping during operation

• Powerful motor with 380 W Continuous Input Rating

• Sliding On / Off thumb switch

• On-board hex wrench storage

• Removes continuous metal curl with

no distortion

• 360° rotatable shear head

Straight Shears

JS1000 SPECIFICATIONS

Maximum Capacities:

Steel

20 ga. (1.0 mm)

Aluminum

12 ga. (2.5 mm)

AMPS (120V)

3.3 A

Strokes Per Minute

4,500 SPM

Minimum Cutting Radius 1-3/16˝ (30 mm)

Overall Length

12-5/8˝ (322 mm)

Net Weight

3.1 lbs (1.4 kg)

JS1601 SPECIFICATIONS

Maximum Capacities:

Steel

16 ga. (1.6 mm)

Aluminum

12 ga. (2.5 mm)

AMPS (120V)

3.3 A

Strokes Per Minute

4,500 SPM

Minimum Cutting Radius 9-7/8˝ (250 mm)

Overall Length

12-5/8˝ (320 mm)

Net Weight

3.1 lbs (1.4 kg)

JS1000 - 20 ga Straight Shear

JS1601 - 16 ga Straight Shear

STANDARD EQUIPMENT INCLUDES:

Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8), Die (A-15051), Punch (A-83951)

Clean, Precise Work In Keystone Plate, Deck Plate And

Other Corrugated Sheet Materials

• Die rotates 360

with positive stops at 0

, 90

Left, 90

Right and 180

for simple and accurate

adjustment on the jobsite

• Large 1/4˝ stroke

• Ergonomic slim body design for easy gripping

• Built-in thickness gauge for operator convenience

• Easy punch and die replacement for less down time

• Sliding lock-on switch for operator convenience

16 ga Nibbler

SPECIFICATIONS

Maximum Capacities:

Mild Steel

16 ga. (1.6 mm)

Stainless

18 ga. (1.2 mm)

Aluminum

13 ga. (2.5 mm)

AMPS (120V)

5.0 A

Strokes Per Minute

2,200 SPM

Minimum Cutting Radius:

Outside Edge

2˝ (50 mm)

Inside Edge

1-3/4˝ (45 mm)

Overall Length

10-1/4˝ (261 mm)

Net Weight

3.5 lbs (1.6 kg)

JN1601

Makita offers a wide variety of

ACCESSORIES!
