Makita General Catalogue

Electric

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY & SERVICE

Counts – Choose Makita

STANDARD EQUIPMENT INCLUDES:

Socket Wrench 9 (782209-3), Wrench Holder 3.4 (410048-8),Triangular Rule (762001-3), High Speed Steel Blades (B-02870)

2-Blade Cutter Head Makes

24,000 CPM

• Unrivaled for power, size and performance

• Larger and sturdy sole plate for added stability

• Front roller for easy moving over rough materials

• Guide rule for accurate and maximum use of

planing width

• Poly ˝V˝ belt designed with grooves efficiently

transfers power from the motor to the blades

• Large ejection chute provides high

rate of chip discharge

12-1/4˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

12-1/4˝ (312 mm)

Planing Depth

1/8˝ (3.5 mm)

No Load Speed

12,000 RPM

AMPS (120V)

15.0

Cord Length

33 ft. (10 m)

Overall Length

21-3/4˝ (551 mm)

Net Weight

40.6 lbs (18.4 kg)

KP312

STANDARD EQUIPMENT INCLUDES:

6-3/4˝ HSS Planer Blades (793186-4), Sharpening HolderAssembly (123006-2), Hex Wrench 4 (783202-0),Triangular Rule (762001-3),

Guide Rule (123053-3), Wooden Carrying Case (no replacement)

30,000 Cuts Per Minute

• Unrivaled for power, size and performance

• Large Base Plate for maximum stability

• Machined Aluminum Base for planing accuracy

• Depth Adjustment Knob for precision

planing applications

• Lock-On Button enables easy continuous operation

6-3/4˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

6-3/4˝ (170 mm)

Planing Depth

1/16˝ (2 mm)

No Load Speed

15,000 RPM

AMPS (120V)

10.9 A

Overall Length

20-3/4˝ (529 mm)

Net Weight

19.8 lbs (9.0 kg)

1806B

STANDARD EQUIPMENT INCLUDES:

4-3/8˝ HSS Planer Blades (793008-8), Blade GaugeAssembly (123010-1), Sharpening HolderAssembly (123055-9),

Socket Wrench 9 (782209-3), Guide Rule Set (191455-1)

32,000 Cuts Per Minute

• Single Chamfering Groove enables quick and

easy chamfering of corners

• Depth Adjustment Knob for precision

planing applications

• Machined Aluminum Base for planing accuracy

• Lock-On Button enables easy continuous operation

4-3/8˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

4-3/8˝ (110 mm)

Planing Depth

1/16˝ (2 mm)

No Load Speed

16,000 RPM

AMPS (120V)

7.5 A

Overall Length

14˝ (355 mm)

Net Weight

9.5 lbs (4.3 kg)

1911B

STANDARD EQUIPMENT INCLUDES:

3-1/4˝DoubleEdgedMiniPlanerBlades(A-82921),BladeGaugeAssembly(123010-1),SocketWrench9(782209-3),GuideRule(122785-9),

Depth Guide (342390-8)

Heavy Duty, Lightweight Design For High Efficiency Surface Planing

• Soft Start feature gradually increases speed to eliminate start up shock

• Base Plate Foot protects materials and blade from damage

• Three Chamfering Grooves enable quick and easy chamfering of corners

• Depth Adjustment Knob with Click Stops for precision planing applications

• Lock-On Button enables easy continuous operation and can be operated from left or right side

• Left or Right Side Chip Ejection

Soft Start

3-1/4˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

3-1/4˝ (82 mm)

Planing Depth 0 - 5/32˝ (0 - 4 mm)

Shiplapping

0 - 1˝ (0 - 25 mm)

No Load Speed

16,000 RPM

AMPS (120V)

7.5 A

Overall Length

11-3/8˝ (290 mm)

Net Weight

7.3 lbs (3.3 kg)

KP0810

STANDARD EQUIPMENT INCLUDES:

KP0800:

3-1/4" Double Edged Mini Planer

Blades (D-16966), Blade GaugeAssembly

(123010-1), Socket Wrench 9 (782209-3),

Guide Rule (165581-2)

KP0800KX:

Two 3-1/4" Double Edged Mini

Planer Blades Sets (D-16966), Blade Gauge

Assembly (123010-1), Socket Wrench 9

(782209-3), Guide Rule (165581-2),

Plastic Carrying Case (824892-1)

Lightweight Design For Easy

Surface Planing

• Base Plate Foot protects materials and blade

from damage

• Single Chamfering Groove enables quick and

easy chamfering of corners

• Depth Adjustment Knob with Click Stops

for precision planing applications

• Lock-On Button enables easy continuous

operation and can be operated from left

or right side

3-1/4˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

3-1/4˝ (82 mm)

Planing Depth 0 - 3/32˝ (0 - 2.5 mm)

Shiplapping

0 - 11/32˝ (0 - 9 mm)

No Load Speed

17,000 RPM

AMPS (120V)

6.5 A

Overall Length

11-1/4˝ (285 mm)

Net Weight

5.7 lbs (2.6 kg)

KP0800

KP0800KX

STANDARD EQUIPMENT INCLUDES:

3-1/4˝ Double Edged Mini Planer Blades (D-16966),

Blade GaugeAssembly (123010-1),

Socket Wrench 9 (782209-3)

32,000 Cuts Per Minute

• Single Chamfering Groove enables quick

and easy chamfering of corners

• Depth Adjustment Knob for precision

planing applications

• Machined Aluminum Base for planing accuracy

• Lock-On Button enables easy

continuous operation

3-1/4˝ Planer

SPECIFICATIONS

Maximum Capacities:

Planing Width

3-1/4˝ (82 mm)

Planing Depth

1/32˝ (1 mm)

No Load Speed

16,000 RPM

AMPS (120V)

5.2 A

Overall Length

11-3/8˝ (290 mm)

Net Weight

6.0 lbs (2.7 kg)

1902
