Makita General Catalogue

89 / 180

Electric Power Tools
89
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
STANDARD EQUIPMENT INCLUDES:
PinEnd15TPIScrollSawBlade(351011-000),Hex
WrenchM3(040005-003),HexWrenchM4(040006-001),
BladeChangeRod(040026-001)
Accepts Pin End And Plain Type Scroll Saw Blades
• Bevel Cuts up to 45° Left and 15° Right
• Blade Tension Lever enables quick adjustment of blade tension
SPECIFICATIONS
Blade Type Plain or Pin End
Blade Length 5˝ (127 mm)
Maximum Capacities:
Length Of Stroke 7/8˝ (22.2 mm)
Throat 16˝ (406.4 mm)
Thickness Of Cut 2˝ (50.8 mm)
No Load Speed 400 - 1,600 SPM
AMPS (120V) 1.2 A
Table Size 14-3/4˝ x 9-3/8˝
(365 mm x 238 mm)
Net Weight 31.1 lbs (14.1 kg)
SJ401 Scroll Saw
SCROLL SAW BLADES
End
Type
Teeth
Type
Teeth
per Inch
(TPI)
Application MaterialThickness
Qty
per
Pack
For
Model
Universal
Blade No.
Part
No.
Pin
End Skip 18.5
Smooth cuts in
thin wood
or plastics
3/32" - 1/2" 6
SJ401
- 722100-A
Plain
End
Reverse
Skip 11.5
Smooth,
splinter free
cuts in hard
and soft wood
> 1/4" 12 7R 722103-A
Variable
Speed
STANDARD EQUIPMENT INCLUDES:
4˝ CTCutter Blade 6T(A-95118),Angle Guide (123148-2), Dust Bag (123150-5),
Lock Nut Wrench 20 (782401-1), Set Plate (415579-2), Plastic Carrying Case (821509-7)
Lightweight And Compact Design With Enhanced
Ergonomics For Maximum Maneuverability
• Depth Adjustment Knob enables quick adjustment
for #0, #10 and #20 biscuits
• Rack-and-Pinion Angle Guide enables precise
adjustment of fence
• Cast Aluminum Adjustable Fence with positive
stops at 0°, 45° and 90°
SPECIFICATIONS
Blade Diameter 4˝ (100 mm)
Maximum Cutting Depth 3/4˝ (20 mm)
No Load Speed 11,000 RPM
AMPS (120V) 5.6 A
Overall Length 11-7/8˝ (302 mm)
Net Weight 5.6 lbs (2.5 kg)
PJ7000 4˝ Plate Joiner
PLATE JOINER BISCUITS
Size Material Dimensions For
Model
100 / Pk
Part No.
#0
Biscuit Compressed
Beechwood
5/8" x 1-7/8"
3901
PJ7000
DPJ180
441001A
#10
Biscuit 3/4" x 2-1/8" 441002A
#20
Biscuit 15/16" x 2-1/4" 441003A
WHEEL SANDER ABRASIVE WHEELS
Description Grit Application For Model Part No.
Slit Paper
Wheel 40G Sanding
9741
794380-1
Wire Brush
Wheel - Metal Finishing 794382-7
Cotton Buff
Wheel - Polishing 794381-9
Nylon Brush
Wheel
80G Coarse Sanding 794384-3
100G Medium Sanding 794379-6
240G Fine Sanding 794383-5
Perfect For Timber Framing And Log Home Building
• Cuts lap joints up to 5-1/8˝
• Notches or cuts holes in thick wood stock quickly
cleanly and accurately
• Quick horizontal chain lever for widening holes
SPECIFICATIONS
Capacities:
Max. Hole Width:
(Longitudinal) 5-1/8˝ (130 mm)
Max. Hole Width:
(Transverse) 1-1/4˝ (31.5 mm)
Max. Hole Depth 6-1/8˝ (155 mm)
No Load Speed 3,200 RPM
AMPS (120V) 10.5 A
Dimensions 20-1/8˝ x 11-3/4˝ x 20-1/4˝
(512 mm x 298 mm x 513 mm)
Net Weight 38.1 lbs (17.3 kg)
Chain Mortiser
STANDARD EQUIPMENT INCLUDES:
5/8˝ Cutting Chain (A-16570), Chain BarAssy (133571-3),
Wrench 13-17 (781204-0), Oil Supply (182229-1)
7104L
CHAIN MORTISER ACCESSORIES
Part No. Description Dimensions For Model
122235-4 Chain Bar for 30 mm Gauge Chain -
7104L
133571-3 Chain Bar Assembly for All Other Gauge Chain -
123028-2 Sharpening Holder Assembly -
221502-5 Chain Sprocket 1-3/16" / 30 mm
A-16564
Cutter Chain
9/16" / 15 mm
A-16570 5/8" / 16.5 mm
A-16586 11/16" / 18 mm
A-16592 51/64" / 21 mm
A-16601 15/16" / 24 mm
A-16617 1-3/16" / 30 mm
Unique Design - Fast, Easy And Controlled Operation
• Fast and efficient paint and rust removal
• Well balanced design with a low center of
gravity and large front
loop handle for
easy handling
SPECIFICATIONS
Wheel Size 3-15/16˝ x 4-23/32˝ (100 mm x 120 mm)
No Load Speed 3,500 RPM
AMPS (120V) 7.8 A
Overall Length 12-1/4˝ (310 mm)
Net Weight 9.3 lbs (4.2 kg)
4-3/4˝ Wheel Sander 9741
STANDARD EQUIPMENT INCLUDES:
Joint (P-80014),Two Hex Wrenches 6 (783204-6), Nylon Brush Wheel 120-100 (794379-6)
