24
BATTERY AND CHARGER TIME REFERENCE CHART (MINUTES)
Voltage CellType Ah Style Model No. Part No.
DC18RCDC18RD DC18SFDC18SDDC18SE
(Automotive)
DC10SB DC07SA
18V Li-Ion
6.0 Slide-On BL1860B* 197424-0 55 55 55 130 130 130 - - -
5.0 Slide-On BL1850B* 196675-2 45 45 45 110 110 110 - - -
4.0 Slide-On BL1840B* 196401-9 36 36 36 90 90 90 - - -
3.0 Slide-On BL1830B* 194205-3 22 22 22 60 60 60 - - -
1.5 Slide-On BL1815N 196235-0 15 15 15 30 30 30 - - -
DC18RE
* Charge Level Indicator ** Available for Warranty replacement only
Automatic Charging Controls
The rapid charger’s CPU communicates with the battery’s onboard data chip. After analyzing the
battery condition, it automatically charges for extended performance and cycle life.
Charging
Display
Controls
Shows battery’s current
condition and charge level
indicators.
Forced Air Cooling Fan
Cools the battery by forcing cool air
through the battery’s built-in air vents to
minimize charging time.
USB Port
Enables convenient
charging of mobile
devices on the jobsite.
DC18RD
Rapid Charging System
Regulates Thermal, Voltage and Current
during Charging Cycle to ensure Battery cannot be
Over-Charged or Over-Heated during the Charging Process
DC18RD Accepts 18V BL1815N
BL1830B / BL1840B / BL1850B
BL1860B Li-Ion Batteries
18V LXT DUAL-PORT RAPID CHARGING SYSTEM
Charges TWO Batteries Simultaneously
DC18RD
LITHIUM-ION BATTERY CHARGERS
Model Description Model Description
18V Li-Ion 4-Port Multi-Charger - DC18SF
• Charges two 18V Li-Ion Batteries at once
• Optimum Charging System
• Charges 2 x 18V (6.0 Ah) Li-Ion Batteries in 130 minutes
• Charges 4 x 18V (6.0 Ah) Li-Ion Batteries in 260 minutes
18V Li-Ion Dual Port Rapid Charger - DC18RD
• Charges 2 x 18V Li-Ion Compact Batteries in 15 minutes!
• Charges 2 x 18V Li-Ion (3.0 Ah) Batteries in 22 minutes!
• Charges 2 x 18V Li-Ion (4.0 Ah) Batteries in 36 minutes!
• Charges 2 x 18V Li-Ion (5.0 Ah) Batteries in 45 minutes!
18V Li-Ion Rapid Charger - DC18RC
• Forced Cooling System
• Charges 18V (6.0 Ah) Li-Ion Battery in 55 minutes
• 3 Active Controls System (Current, Voltage & Temperature)
provides an optimal charge and ensures Battery cannot be
overcharged or overheated during the charging process
18V Li-Ion Standard Charger - DC18SD
• Charges 14.4V - 18V Li-Ion and Ni-MH Slide Style Batteries
• Charges 18V (6.0 Ah) Li-Ion Battery BL1830B in 130 minutes
• Digital Power Display indicates condition of Battery
and current charge level (-80%, +80%, 100%)
18V Li-Ion / 12V MAX CXT Li-Ion
Dual-Port Rapid Charger - DC18RE
• Charges 12V MAX CXT (BL1016, BL1021B, BL1041B)
and 18V Li-Ion (BL1815N, BL1830B, BL1840B, BL1850B,
BL1860B) Batteries
• Enables two Batteries to be charged in sequence
18V Li-Ion Automotive Charger - DC18SE
• Charges 7.2V - 18V Ni-Cad, Ni-MH and Li-Ion Slide Style Batteries
• Plugs into standard 12V / 24V DC Automotive outlets
• Charges 18V (6.0 Ah) Li-Ion Battery in 130 minutes
• Use with Adapter ADP04 (Part No. #193949-2)
to charge pod / stick style Batteries
DC10WD
CHARGERS & BATTERIES
DC18RE
