Layout 1

28 / 32

26
L CLASS DUST EXTRACTORS
Model No. VC4210L VC3012L VC2512L
Model Name L Class Automatic Filter Cleaning
42.0 L Dust Extractor
L Class Push & Clean Filter Cleaning
30.0 L Dust Extractor
L Class Push & Clean Filter Cleaning
25.0 L Compact Dust Extractor
Container Capacity 42.0 L 30.0 L 25.0 L
Dry Tank Capacity 34.0 L 24.0 L 21.0 L
Wet Tank Capacity 30.0 L 19.0 L 18.0 L
Maximum Air Flow 148 CFM 113 CFM 127 CFM
Static Water Lift 101" (255 cm) 101" (255 cm) 84.4" (214 cm)
AMPS (120V) 7.4 A 7.0 A 9.4 A
Power Cord Length 24.6 ft (7.5 m) 24.6 ft (7.5 m) 24.6 ft (7.5 m)
Noise Level 60 dB(A) 59 dB(A) 64 dB(A)
Overall Length 22-5/8" (575 mm) 19-3/8" (500 mm) 15-5/8" (395 mm)
Net Weight 35.3 lbs (16.0 kg) 22.0 lbs (10.0 kg) 17.4 lbs (8.0 kg)
Model No. Description Includes
VC4210L L Class Automatic Filter Cleaning
42.0 L Dust Extractor
HEPA Filter (W107413555), Fleece Filter Bag (1 Ea. W107418353), Disposal Bag (1 Ea. W107418355),
1-3/8" x 13' Anti-Static Suction Hose (Features Quick Connect Coupling) (P-84084), Quick Connect Tool Adapter (P-70378),
Tool Adapter (W107418688), Crevice Nozzle (P-80005), Two Interlocking Case Holder (W107418357), Adapter 35/38 (P-70421)
VC3012L L Class Push & Clean Filter Cleaning
30.0 L Dust Extractor
Floor Nozzle (P-81789), Extension Tubes (P-70437), 12" Crevice Nozzle (P-80005), Tool Adapter 38 (W107418688),
Tool Adapter 22 (W107418678), Curved Tube Handle (P-70346), Quick Connect Tool Adapter (P-70378),
1-3/8" x 13' Anti-Static Suction Hose (Features Quick Connect Coupling) (P-84084), Nano Fleece Filter Bag (1 Ea. P-84078),
HEPA Filter (T-01806), Plastic Disposal Bag (1 Ea. P-70297)
VC2512L L Class Push & Clean Filter Cleaning
25.0 L Compact Dust Extractor
Floor Nozzle (W107402706), Extension Tubes (P-72942), Crevice Nozzle (W295410000), Universal Nozzle (W142950000),
Tool Adapter (W107409977), 1-1/4" x 11' Suction Hose (W107406115), Filter Bag (P-72899), Plastic Disposal Bag (1 Ea. P-70297),
PET Fleece Filter Cartridge (P-70219), Accessory Tool Box (W107409980),Tool Adapter 38 (W107418680), Tool Adapter 22 (W107418661)
MODEL & COMBO KIT SPECIFICATIONS
Interlocking
Case Holder
mounted on the
machine!
InterlockingCaseSoldSeparately
Wet & Dry Wet & Dry
Wet & Dry
L CLASS DUST EXTRACTOR BRUSH & NOZZLE SETS
Part Number Description Includes For Models
P-70502
4 Piece Brush
& Nozzle Set
For 1-3/8" Hose
• 12" Crevice Nozzle (P-80005)
• 1-3/4" x 5" Rectangular Brush Nozzle (P-70471)
• Brush, Universal Nozzle
Note: Brush & Universal Nozzle Not Available Separately
VC4710
446L
VC3012L
VC2512L
P-70518
3 Piece Brush
& Nozzle Set
For 1-3/8" Hose
• 1-3/4" x 2-3/4" Square Brush Nozzle (P-80004)
• Rubber Tube Nozzle
• Universal Nozzle
Note: Rubber Tube Nozzle & Universal Nozzle
Not Available Separately
VC4710
446L
VC3012L
VC2512L
P-70312
8 Piece Brush
& Nozzle Set
For 1-3/8" Hose
• Floor Nozzle with Carpet Shift (P-70465)
• 1-3/4" x 2-3/4" Square Brush Nozzle (P-80004)
• Universal Nozzle
• 12" Crevice Nozzle (P-80005)
• Pipe Holder (W302004027)
• Two 19" Extension Tubes (P-70437)
• Curved Tube Handle (P-70346)
Note: Universal Nozzle Not Available Separately
VC4710
446L
VC3012L
VC2512L
VC4210L
