DUST EXTRACTION
Xtract Vac
TM
Automatic Filter Cleaning
System clears filter at regular intervals
to maximize filter efficiency and
maintain suction power
• Rocker Valve isolates each filter during cleaning process to prevent
interruption of suction power
• Onboard Outlet and Automatic Start Feature enables dust extractor to be
operated in conjunction with power tools
SPECIFICATIONS
Container Capacity
45.4 L
Dry Tank Capacity
34.0 L
Wet Tank Capacity
30.2 L
Maximum Air Flow
0 - 135 CFM
Standard Filter Particulate Rating
2 microns
Static Water Lift
92" (233 cm)
AMPS (120V)
12.0 A
Power Cord Length
26.25' (8 m)
Overall Length
29-1/2" (750 mm)
Net Weight
27.0 lbs (12.3 kg)
STANDARD EQUIPMENT INCLUDES:
Nano Fleece Filter Bag (1 Ea. P-78293), Plastic Disposal Bag (1 Ea. P-70297), Nano Fleece Filter (1 Ea. P-79843), 1-3/8" x 9-1/2'Anti-Static Suction Hose
(Features P-70421 1-3/8" Hose Joint) (P-79865), 12˝ Crevice Nozzle (P-80005)
VC4710
L Class
Automatic Filter Cleaning 45.4 L Dust Extractor
Variable Speed
Control Dial
Onboard Tool
Activated Outlet
Wet & Dry
Push & Clean Filter System clears particulate and debris from clogged
filters to maximize filter efficiency and maintain suction power
• Onboard outlet and automatic start feature enables dust extractor to be operated in conjunction with power tools
• For wet and dry vacuuming cleaning
• Variable settings enable operator to adjust the suction power to the application
• Push and clean system
• Washable HEPA Filter cartridge filter protects turbine by holding back fine dust and debris
• Automatic on / off function
• Polycarbonate shell with 2 wheels and 2 castors for excellent stability and mobility
SPECIFICATIONS
Container Capacity
30.0 L
Dry Tank Capacity
24.0 L
Wet Tank Capacity
19.0 L
Maximum Air Flow
0 - 113 CFM
Static Water Lift
101" (255 cm)
AMPS (120V)
7.0 A
Power Cord Length
24.6' (7.5 m)
Overall Length
19-3/8" (500 mm)
Net Weight
22.0 lbs (10.0 kg)
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (P-81789), ExtensionTubes (P-70437), 12" Crevice Nozzle (P-80005),
Front Cuff 32 (W14682), CurvedTube Handle (P-70346), Quick ConnectToolAdapter (P-70378),
1-3/8" x 13'Anti-Static Suction Hose (Features Quick Connect Coupling) (P-84084),
Nano Fleece Filter Bag (1 Ea. P-84078), HEPAFilter (T-01806), Plastic Disposal Bag (1 Ea. P-70297)
VC3012L
L Class
Push & Clean Filter Cleaning 30.0 L Dust Extractor
Wet &
Dry
MAXIMUMAIR FLOW
The
AMOUNT
of air being drawn in by the turbine. Typically measured in cubic feet per minute (CFM)
Push & Clean Filter System clears particulate and debris from clogged
filters to maximize filter efficiency and maintain suction power
• Onboard Outlet and Automatic Start Feature enables dust extractor to be operated in conjunction with power tools
• For Wet and Dry vacuuming cleaning
• Variable Settings enable operator to adjust the suction power to the application
• Push and clean system
• Washable PET cartridge filter protects turbine by holding back fine dust and debris
• Automatic On / Off function
• Polycarbonate shell with 2 wheels and 2 castors for excellent stability and mobility
• 11' Anti-static hose and grounded canister prevents buildup of static charges
• Floor nozzles and extension tubes can be fixed onto the body for convenient storage
SPECIFICATIONS
Container Capacity
25.0 L
Dry Tank Capacity
21.0 L
Wet Tank Capacity
18.0 L
Maximum Air Flow
127 CFM
Static Water Lift
84.4" (215 cm)
AMPS (120V)
9.4 A
Power Cord Length
24.6' (7.5 m)
Overall Length
15-5/8" (395 mm)
Net Weight
17.4 lbs (8.0 kg)
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (W107402706), ExtensionTubes (P-72942), Crevice Nozzle (W295410000), Universal Nozzle (W142950000),ToolAdapter (W107409977),
1-1/4" x 11' Suction Hose (W107406115), Filter Bag (P-72899), Plastic Disposal Bag (1 Ea. P-70297), PETFleece Filter Cartridge (P-70219),AccessoryTool Box (W107409980)
Variable Speed
Control Dial
VC2512L
L Class
Push & Clean Filter Cleaning 25.0 L Compact Dust Extractor
Wet & Dry
