142 / 220
DRILLS
makita.ca
140
DA4000LR
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (193319-5), Chuck Key (763434-5), Side Handle
(For tool barrel) (152892-4), Side Handle (Angle) (122646-3),
Hex Wrench 5 (783216-9), Plastic Carrying Case (824646-6)
Angle Attachment Rotates 360°
To Drill In Any Position
• Durable / Dust-Proof Switch featuring large
trigger for comfortable operation
• Industrial metal gear housing for durability and
long tool life
• Angle attachment may be removed and drill
used as a straight drill
Variable 2-Speed,
Reversible
1/2" Angle Drill
SPECIFICATIONS
Drilling capacities:
Wood: Auger-bit Low: 1-1/2" (38 mm)
High: 1-1/2"(38 mm)
Self-feed bit: Low: 4-5/8" (118 mm)
High: 2-9/16
"
(65 mm)
Hole saw:
Low: 6
"
(152 mm)
High: 4-1/2
"
(114 mm)
Steel: Twist Bit
1/2
"
(13 mm)
AMPS (120V)
7.5 A
No Load Speed:
Low: 0 - 400 RPM
High: 0 - 900 RPM
Overall Length
16-1/4
"
(413 mm)
Net Weight
8.8 lbs (4.0 kg)
5-1/2"
DA3010F
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763174-5), Chuck Key (763415-9), Side Handle (153489-2)
Built-In LED Job Light For Excellent
Work Efficiency
• Industrial metal gear housing for durability and
long tool life
• Reduced head height (2-5/8") for working in
limited space
• Ball bearing construction for longer motor life
• Paddle switch with speed limiting dial
• Compact (10-5/8" length) design for easy use
when working between framing studs or any
other close quarter application
Variable Speed,
Built-In LED Job Light
3/8" Angle Drill
SPECIFICATIONS
Capacities:
Wood
1" (25 mm)
Steel
3/8" (10 mm)
No Load Speed
0 - 2,400 RPM
AMPS (120V)
4.0 A
Overall Length
10-5/8" (270 mm)
Net Weight
3.5 lbs (1.6 kg)
2-5/8"
RIGHT ANGLE DRILL ATTACHMENTS
• Ideal for buffing and sanding
• Reaches into tight places and rotates 360º in any direction
No Load Speed For Model(s)
Part No.
Low: 350 RPM
High: 800 RPM
6013BR / K
DS4011 / K 122177-2
Low: 400 RPM
High: 900 RPM DA4000LR 193316-1
GREASE GUNATTACHMENT FORCORDLESSOR ELECTRIC TOOLS
T-01797
Description
Ideal for Heavy Equipment, Industrial Machines & Equipment, Farm and Garden Vehicles,
Recreational Vehicles, Automobiles, Boats and more!
• Fully Automatic Grease Dispensing
• Pressure Vent Protector prevents pressure overload for maximum operator safety
• 3 Filling Modes - 14 oz. Grease Cartridges, Bulk or Bulk Dispenser
• 4,000 PSI Recommended Working Pressure (8,000 PSI (+/- 500 PSI) Maximum Rated Pressure)
• Tool Holder accepts tools with a body diameter of 1-1/2" - 3"
• Features 1/4" Hex Drive Shank for quick attachment to power tool
• Can be operated with Cordless or Electric Drills / Drivers, Hammer Drills / Drivers
*
, Impact Drivers and Impact Wrenches
+
•
INCLUDES:
18" Grease Hose (T-01828) (Optional 12" Grease Hose (Part No. T-01812), 24" Grease Hose (T-01834)
and 48" Grease Hose (T-03274) available)
* (Note - This product should not be operated on "Hammer" mode) + (Note -Adapter required for use with Impact Wrenches)
Optional 30˝ Extension Handle available
(Part No. 193317-9)
GLASS & TILE DRILL BITS
Diameter
Overall Length
Part No.
1/8"
2-1/2"
D-25183
3/16"
2-1/2"
D-25199
1/4"
1/4" x 3"
D-25208
5/16"
5/16" x 3"
D-25214
3/8"
3-1/8"
D-25220
1/2"
3-1/8"
D-25236
• For tiles, ceramics, and glass
• Precision ground carbide tip for clean and accurate holes
MASONRYDRILL BITS
Diameter
Overall Length Usable Length Shank Type
Part No.
1/8"
3"
1-11/64"
1/4" Hex
D-24038
3/16"
3-11/32"
1-9/16"
D-24044
1/4"
4"
2-5/32"
D-24050
• Hex shank design allows for quick and convenient bit changes
• For use drilling holes in masonry
• 1/4" hex shank suitable for use in impact drivers, 3/8", and 1/2" drills
