STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763136-3), Chuck Key (763403-6C)
Multi-Purpose Drill For Wood And Metal
• Separate reversing switch for ease of operation
• High power-to-weight ratio 3.1 lbs (1.4 kg)
• Variable speed (0-1,200 RPM) for drilling in a wide variety of materials
• Double reduction gear design for extra torque
• Conveniently located lock-on-button for continuous use
• Industrial 3/8" chuck for accurate drilling
Variable Speed, Reversible
3/8" Drill
SPECIFICATIONS
Capacities:
Steel
3/8" (10 mm)
Wood
3/4" (18 mm)
No Load Speed
0 - 1,200 RPM
AMPS (120V)
3.5 A
Overall Length
9-1/2" (242 mm)
Net Weight
3.1 lbs (1.4 kg)
6510LVR
STANDARD EQUIPMENT INCLUDES:
Keyless Chuck (763132-1), Plastic Carrying Case (A82500-7)
General Purpose Entry Level Drill For Light Drilling
• Keyless chuck for fast and easy bit installation and removal
• Variable speed (0 - 2,500 RPM) for drilling in a wide variety of materials
• Low decibel rating (79 dB) for quieter operation
Variable Speed, Reversible
3/8" Drill
SPECIFICATIONS
Capacities:
Steel
3/8" (10 mm)
Wood
1" (25 mm)
No Load Speed
0 - 2,500 RPM
AMPS (120V)
4.9 A
Overall Length
10-1/4" (261 mm)
Net Weight
3.3 lbs (1.5 kg)
6408K
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Keyless Drill Chuck (763180-0), Plastic Carrying Case (187043-0)
General Purpose Drill Featuring Compact And Lightweight Design
• All ball bearing construction for smooth and durable operation
• Variable Speed trigger for drilling in a wide variety of materials
• Powerful motor rated at 4.0 Amps with 450W Continuous Input
• Keyless Chuck for quick and easy bit installation and removal
• Forward/Reverse switch for easy switching between operating modes
• Lock-On Button for continuous operation
• Lanyard Loop for attachment of lanyard when working at heights
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible
3/8" Drill
SPECIFICATIONS
Capacities:
Steel
3/8" (10 mm)
Wood
1" (25.4 mm)
No Load Speed
0 - 3,400 RPM
AMPS (120V)
4.0 A
Overall Length
9-1/4" (234 mm)
Net Weight
3.3 lbs (1.5 kg)
6413K
STANDARD EQUIPMENT INCLUDES:
Key Holder (418198-3), Chuck Key (763418-3), 1/4" Drill Chuck (763077-3)
Designed For High Drilling Efficiency
• Variable speed dial enables operator to adjust drilling speed based on materials or application
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
1/4" Drill
SPECIFICATIONS
Capacities:
Steel
1/4" (6.5 mm)
Wood
9/16" (15 mm)
AMPS (120V)
3.2 A
No Load Speed
0 - 4,200 RPM
Overall Length
8-1/4" (209 mm)
Net Weight
2.2 lbs (1.0 kg)
DP2010
DA4031
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (193520-2), Chuck Key (763434-5), Straight Side Handle
(273654-8), Hex Wrench 6 (783204-6), D-Style Front Handle (417665-5),
Plastic Carrying Case (824647-4)
Designed For Efficient Drilling
Between Studs & Joists
• Ergonomic design ensures best performance
while drilling in frame construction, plumbing
and electrical work
• Tool-free rear handle swivels 90° Left or
Right for easy drilling
• Built in torque limiter stops drill bit rotation
when bit hits reinforcements
1/2" Angle Drill
SPECIFICATIONS
Drilling capacities:
Wood:
Auger-bit
1-1/2" (38 mm)
Self-feed bit
4 -5/8" (118 mm)
Hole saw
6" (152 mm)
Steel:
Twist bit
1/2" (13 mm)
AMPS (120V)
10.0 A
No Load Speed:
Low
300 RPM
High
1,200 RPM
Overall Length
18-1/4" (462 mm)
Net Weight
13.9 lbs (6.3 kg)
5-1/2"
Torque Limiter
DA6301
1/2" Angle Drill
2 Speed, Reversible,
Torque Limiter
SPECIFICATIONS
Drilling Capacities:
Steel
1/2" (13 mm)
Wood
1-3/8" ( 36 mm)
AMPS (120V)
7.5 A
No Load Speed:
Low
300 RPM
High
1,200 RPM
Overall Length
16-1/8" (410 mm)
Net Weight
10.4 lbs (4.7 kg)
STANDARD EQUIPMENT INCLUDES:
Drill Chuck (763062-6), Chuck Key (763432-9), Side Handle (273476-6), D-Style Front Handle (273628-9), Steel Carrying Case (181791-3)
For Heavy Duty Drilling
With Torque Limiter
• Double reduction gearing for maximum power
• Ball bearing construction for longer life
• Built in torque limiter stops drill bit rotation
when bit hits reinforcements
• Rocker Switch for easy one handed operation
• Large side handle for controlled handling
7-1/8"
