165 / 220
Electric
Power Tools
makita.ca
163
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
9" DIAMONDBLADE
DUST COLLECTIONCOVER
198509-5
• Plunge cutting action promotes maximum
dust extraction efficiency
• One-touch cutting depth adjustment provides maximum
operator precision
• 360° rotatable dust extraction port easily adapts to
Makita dust extractors
• Clear window for viewing blade tip enables maximum
visibility and accuracy
• Front / rear rollers, and rounded base plate leading edge
enable smooth movement across materials
• Quick release blade cover allows operator to easily
change blades
• Side handle offers maximum operator control
• Max cutting depth: 2-3/8”
One-touch cutting depth
adjustment provides maximum
operator precision
VACUUMBRAZEDDIAMONDRESCUEWHEELS
IDEAL FOR FIRE DEPARTMENTS, RESCUE SERVICES, CONTRACTORS AND MORE!
• Developed specifically for rescue operations, including cutting through airplanes, trains and crash barriers
• A time and cost saving alternative to multi-material cutting applications for contractors and renovators
• Vacuum brazed diamond segments for optimum operational life and consistent performance
• Ideal for cutting steel, stainless steel, alloys, aluminum, resin, PVC, concrete, reinforced glass, fibre-reinforced plastics and more!
• Ideal for use with Makita 4-1/2" - 9" AC or DC Angle Grinders!
Blade Diameter
Arbor
Rim Type
Wet / Dry
Application
Max. RPM
For Model(s)
Part No.
4-1/2"
7/8"
Segmented
Rim
Dry
Steel, stainless steel, alloys,
aluminum, resin, PVC, concrete,
reinforced glass,
fibre-reinforced plastics
13,300
4-1/2" Angle
Grinders
B-56960
5"
12,250
5" & 6" Angle
Grinders
B-56976
9"
6,650
9" Angle
Grinders
B-56982
OPTIMUMSERIESDIAMONDBLADES
• Optimum Bond Matrix provides the optimal balance between wear, fracture and exposure in order to maximize the
cutting ability of the diamond content
• Optimum Diamond Blades cut Faster, Longer and Smoother in a variety of materials
• Highest Quality Diamond Content to enable maximum cutting ability
• Superior Quality Steel Core for maximum stability and durability
• Laser Welded (Segmented Rim Blades) or Sintered (Continuous Rim Blades) to ensure the strongest possible joints
• Available in Segmented, Turbo and Continuous Rims
Blade Diameter
Arbor
Rim Type
Wet / Dry Material Type
Application
Max. RPM
For Model(s)
Part No.
7"
5/8"
Turbo Rim
Wet or Dry
Hard
Granite, Ceramic, Fire Brick
8,700
7" Angle Grinders
A-94611
5/8", 7/8"
Diamond
Segmented Rim
Medium
Cured Concrete, Block,
Brick, Masonry
8,500
A-94714
Turbo Rim
A-94574
5/8", 7/8" Continuous Rim
A-95087
5/8"
Turbo Rim
Soft
Brick, Sand Stone, Concrete Block
8,700
A-94649
6"
5/8", 7/8" Segmented Rim Wet or Dry Medium Cured Concrete, Block, Brick, Masonry 10,100
6" Angle Grinders
A-94708
5"
20 mm
5/8", 7/8"
Turbo Rim
Wet or Dry
Hard
Granite, Ceramic, Fire Brick
12,200
5" Angle Grinders
A-94605
Segmented Rim
Medium
Cured Concrete, Block,
Brick, Masonry
A-94699
Turbo Rim
A-94568
Continuous Rim
A-95152
4-1/2"
20 mm
5/8", 7/8"
Turbo Rim
Wet or Dry
Hard
Granite, Ceramic, Fire Brick
13,800
4-1/2" Angle Grinders
A-94596
Segmented Rim
Medium Cured Concrete, Block, Brick, Masonry
A-94683
Turbo Rim
A-94552
Continuous Rim
A-95071
Turbo Rim
Soft
Brick, Sand Stone, Concrete Block
A-94633
4"
20 mm
5/8", 7/8"
Turbo Rim
Wet or Dry
Hard
Granite, Ceramic, Fire Brick
15,200
4" Angle Grinders
A-94580
Segmented Rim
Medium Cured Concrete, Block, Brick, Masonry 15,300
A-94677
Turbo Rim
A-94546
Continuous Rim
A-95065
14
