160 / 220
METALWORKING
makita.ca
158
STANDARD EQUIPMENT INCLUDES:
9558PB:
5" Depressed Center Wheel (1 Ea.A-95962-25), Wheel Cover (123099-9), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153489-2)
9558NB:
5" Depressed Center Wheel (1 Ea.A-95962-25), Wheel Cover (123734-9), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153489-2)
9558PB
Two Stage Safety Paddle Switch (AC/DC)
9558NB
Thumb Switch with Lock-On (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left hand
• Removable side handle can be mounted on left or right side of tool
5" Angle Grinder
SPECIFICATIONS
Capacities:
Grinding Wheel
5" (125 mm)
Sanding Disc
5" (125 mm)
Wire Cup Brush
3-1/2"(90 mm)
Spindle Thread
5/8"- 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
7.5 A
Overall Length
9558PB
10-3/4" (273 mm)
9558NB
10-5/8" (271 mm)
Net Weight
4.6 lbs (2.1 kg)
9558PB
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
9558NB
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5" (125 mm)
Sanding Disc
5" (125 mm)
Diamond Wheel
5" (125 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
2,800 - 11,000 RPM
AMPS (120V)
12.0 A
GA5042C01:
Overall length 11-7/8" (303 mm)
Net Weight
5.5 lbs (2.5 kg)
GA5043C01:
Overall length 12-3/4" (325 mm)
Net Weight
5.9 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
5" Depressed Center Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8)
Inner Flange (224399-1), Lock Nut 5/8-45(224568-4)
GA5042C01
GA5042C01, GA5043C01
5" Angle Grinders
STANDARD EQUIPMENT INCLUDES:
5" Depressed Center Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8),
Inner Flange (224448-4), Lock Nut 5/8-45(224568-4)
GA5043C01
Mechanical
Brake
SJS Technology,
Variable Speed
STANDARD EQUIPMENT INCLUDES:
5" Depressed Center Wheel (D-20797), Inner Flange (224399-1),Toolless Wheel Cover (123145-8), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6), Side Handle (158237-4)
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Labyrinth construction seals motor and bearings from contamination
• Electronic current limiter protects motor from accidental overload
• Thumb switch conveniently located for operator comfort
• Removable side handle can be mounted on left or right side of tool
• Tool-less wheel guard adjustment
SJS Technology, Variable Speed,
Electronic Current Limiter
5" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5" (125 mm)
Sanding Disc
5" (125 mm)
Diamond Wheel
5" (125 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
2,800 - 10,500 RPM
AMPS (120 V)
12.0 A
Overall Length
11-3/4" (299 mm)
Net Weight
5.3 lbs (2.4 kg)
9565CV
STANDARD EQUIPMENT INCLUDES:
9565P:
5" Depressed Centre Wheel (1 Ea.A-95962-25), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),
Toolless Wheel Cover (123145-8), Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4)
9565PCV:
5" Depressed Center Wheel (1 Ea.A-95962-25), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),
Wheel Cover (123144-0), Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
• Rotatable gear housing can be positioned at every 90°
• Advanced dust-proof construction
5" Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5" (125 mm)
Sanding Disc
5" (125 mm)
Diamond Wheel
5" (125 mm)
Wire Cup Brush
3-1/2" (90 mm)
Spindle Thread
5/8" - 11 UNC
AMPS (120V)
13.0 A
Overall Length
12-1/8" (307 mm)
Net Weight
5.3 lbs (2.4 kg)
9565P
No Load Speed
11,900 RPM
9565PCV
No Load Speed 2,800 - 10,500 RPM
9565P
STANDARD EQUIPMENT INCLUDES:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123145-8), 5" Depressed Center Wheel (A-95962),
Inner Flange (224399-1), Lock Nut 5/8˝-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool
and operator protection
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left
or right side of tool
SJS Technology
5" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5" (125 mm)
Sanding Disc
5" (125 mm)
Diamond Wheel
5" (125 mm)
Wire Cup Brush
3-1/2"(90 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
10,500 RPM
AMPS (120V)
10.0
Overall Length
12-1/8" (307 mm)
Net Weight
5.7 lbs (2.6 kg)
9565PC
9565PCV
Variable Speed
(9565PCV Only)
SJS
Technology
