125 / 180
Electric
Power Tools
makita.ca125
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Side Handle (153504-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (135650-3), 5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Inner Flange (224399-1), Lock Nut (224568-4), Dust CoverAttachment (194482-7)
Trigger Switch with No Lock-On Button (AC/DC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electric Brake for increased operator safety
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of too
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
“SJS” Technology, Electric Brake
5˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding
Wheel 5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
6.0 lbs (2.7 kg)
GA5020
STANDARD EQUIPMENT INCLUDES:
GA5010Z:
Side Handle (153504-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (135650-3), 5˝ Depressed Centre Wheel
(1 Ea.A-95962-25), Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
GA5010:
Side Handle (153504-2), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (135650-3), 5˝ Depressed Centre Wheel
(1 Ea.A-95962-25), Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or
right side of tool
5˝ Angle Grinders
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
10.5 A
Overall Length
14˝ (356 mm)
Net Weight
5.7 lbs (2.6 kg)
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Thumb Switch with Lock-On (AC)
• SJS (Super Joint System) prevents kickback during wheel lock up for optimal tool and operator protection
• Electronic Current Limiter prevents motor burnout due to overloading
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Diamond Wheel
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 11,000 RPM
AMPS (120V)
12.0 A
GA5042C01:
Overall length 11-7/8˝ (303 mm)
Net Wieght
5.5 lbs (2.5 kg)
GA5043C01:
Overall length 12-3/4˝ (325 mm)
Net Wieght
5.9 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8)
Inner Flange 45 (224399-1), Lock Nut 5/8-45(224568-4)
GA5042C01
GA5042C01, GA5043C01
5˝ Angle Grinders
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Anti-Vibration Side Handle (194514-0),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123145-8),
Inner Flange 45B (224448-4), Lock Nut 5/8-45(224568-4)
GA5043C01
Mechanical
Brake
• Powerful 10 amp motor ideal for high
production applications
• Lightweight design reduces operator
fatigue during periods of prolonged use
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
5˝ (125 mm)
Sanding Disc
5˝ (125 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
12,000 RPM
AMPS (120V)
10.0 A
Overall Length
14˝ (356 mm)
Net Weight
6.4 lbs (2.9 kg)
9005BY, 9005BZ, 9005B
5˝ Angle Grinders
Two Stage Safety
Trigger Switch
(AC/DC)
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Wheel Cover (135549-2), Side Handle (152492-0)
Inner Flange (224378-9), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005BY
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Wheel Cover (135549-2), Side Handle (152492-0),
Inner Flange (224378-9), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005BZ
STANDARD EQUIPMENT INCLUDES:
5˝ Depressed Centre Wheel (1 Ea.A-95962-25),
Wheel Cover (135549-2), Side Handle (152492-0),
Inner Flange (224378-9), Lock Nut (224568-4),
Lock Nut Wrench 28 (782412-6)
9005B
Trigger Switch
with No Lock-On
Button
(AC/DC)
Trigger Switch
with Lock-On
Button
(AC/DC)
"SJS" Technology,
Variable Speed
Trigger Switch with
No Lock-On
Button (AC/DC)
GA5010Z
Trigger Switch with
Lock-On
Button (AC/DC)
GA5010
