METALWORKING
128
STANDARD EQUIPMENT INCLUDES:
4˝ Depressed Centre Wheel (D-20775), Lock Nut Wrench 20 (782420-7), Lock Nut (224573-1), Inner Flange (224377-1),
Wheel Cover (125885-4), Side Handle (153504-2), Plastic Carrying Case (824736-5)
Thumb Switch with Lock-On (AC)
• Labyrinth construction seals motor and bearings from contamination
• Zig - Zag varnish on armature and powder coating on field to protect motor from abrasion
• Engineered for durability – double protection against dust, high quality motor and machined gears
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
• Slim housing design for easy handling and maneuverability
• Thumb switch conveniently located for operator comfort
4˝ Angle Grinder With Slim Motor Housing
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel 4˝ (100 mm)
Sanding Disc 4˝ (100 mm)
Wire Cup Brush 3˝ (75 mm)
Spindle Thread M10 x 1.25
No Load Speed 11,000 RPM
AMPS(120V) 6.0 A
Overall Length 10-1/2˝ (266 mm)
Net Weight 3.7 lbs (1.7 kg)
GA4030K
STANDARD EQUIPMENT INCLUDES:
4˝ Depressed Center Wheel (D-20775), Lock Nut Wrench 20 (782420-7), Wheel Cover (125885-4), Inner Flange (224377-1),
Lock Nut (224573-1), Side Handle (153489-2)
Two Stage Safety Paddle Switch (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
4˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel 4˝ (100 mm)
Sanding Disc 4˝ (100 mm)
Wire Cup Brush 3˝ (75 mm)
Spindle Thread M10 x 1.5
No Load Speed 11,000 RPM
AMPS (120V) 7.5 A
Overall Length 10-3/4˝ (273 mm)
Net Weight 4.4 lbs (2.0 kg)
9556PB Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
MAKITA ANGLE GRINDER FEATURES QUICK REFERENCE CHART
Model No. Wheel
Diameter
Power
Source
Rated
Amperage
Switch
Type
Two-Stage
Safety
Switch
Lock-On
Switch
No
Lock-On
Switch
Super Joint
System
(SJS)
Electric or
Mechanical
Brake
Anti-
Restart
Feature
Soft Start
Feature
Constant
Speed
Control
Electronic
Current
Limiter
Torque
Limiter
Variable
Speed
GA4030K 4" AC 6.0 A Thumb ●
9556PB AC/DC 7.5 A Paddle ● ●
DGA452
4-1/2"
18V Li-Ion Thumb ● ● ●
DGA454 18V Li-Ion Thumb ● ● ● ●
DGA455 18V Li-Ion Paddle ● ● ● ●
GA4530K AC 6.0 A Thumb ●
GA4534 AC/DC 6.0 A Paddle ●
GA4542C01 AC 12.0 A Thumb ● ● ● ● ● ●
GA4543C01 AC 12.0 A Thumb ● ● ● ● ● ● ●
SA4542C AC 12.0 A Thumb ● ● ● ● ● ●
9557NB AC/DC 7.5 A Thumb ●
9557PB AC/DC 7.5 A Paddle ● ●
9564P AC/DC 10.0 A Paddle ● ●
9564PCV AC 13.0 A Paddle ● ● ● ● ● ●
DGA504
5"
18V Li-Ion Thumb ● ● ● ●
DGA505 18V Li-Ion Paddle ● ● ● ●
DGA506 18V Li-Ion Thumb ● ● ● ● ●
DGA508 18V Li-Ion Paddle ● ● ● ● ●
GA5010 AC/DC 10.5 A Trigger ●
GA5010 AC/DC 10.5 A Trigger ●
GA5020 AC/DC 10.5 A Trigger ● ● ●
GA5020C AC 12.5 A Trigger ● ● ● ● ● ● ●
GA5020Y AC/DC 10.5 A Trigger ● ● ●
GA5030K AC 6.0 A Thumb ●
GA5042C01 AC 12.0 A Thumb ● ● ● ● ● ●
GA5043C01 AC 12.0 A Thumb ● ● ● ● ● ● ●
9005B AC/DC 10.0 A Trigger ●
9005BY AC/DC 10.0 A Trigger ●
9005BZ AC/DC 10.0 A Trigger ●
9015DB AC/DC 12.5 A Paddle ●
9015DBZ AC/DC 12.5 A Trigger ●
9558NB AC/DC 7.5 A Thumb ●
9558PB AC/DC 7.5 A Paddle ● ●
9565PCV AC 13.0 A Paddle ● ● ● ● ● ●
GA6010
6"
AC/DC 10.5 A Trigger ●
GA6010Z AC/DC 10.5 A Trigger ●
GA6020 AC/DC 10.5 A Trigger ● ● ●
GA6020C AC 12.5 A Trigger ● ● ● ● ● ● ●
GA6020Y AC/DC 10.5 A Trigger ● ● ●
GA6042C01 AC 12.0 A Thumb ● ● ● ● ● ●
9016DB AC/DC 12.5 A Paddle ●
9016DBZ AC/DC 12.5 A Trigger ●
GA7010C
7"
AC 15.0 A Paddle ● ● ● ●
GA7020 AC/DC 15.0 A Paddle ●
GA7031 AC/DC 15.0 A Trigger ● ●
GA7031Y AC/DC 15.0 A Trigger ● ●
GA7050 AC/DC 15.0 A Paddle ●
GA7060 AC 15.0 A Trigger ●
GA7911 7" / 9" AC/DC 15.0 A Trigger ●
GA9031
9"
AC/DC 15.0 A Trigger ● ●
GA9031Y AC/DC 15.0 A Trigger ● ●
GA9060 AC 15.0 A Trigger ●
