127 / 180
Electric
Power Tools
makita.ca127
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
9557PB:
4-1/2˝ Depressed Center Wheel (1 Ea.A-95956-25), Lock Nut Wrench 28 (782424-9), Wheel Cover (123098-1),
Inner Flange (224399-1), Lock Nut (224568-4), Side Handle (153489-2)
9557PBK:
4-1/2˝ Depressed Center Wheel (1 Ea.A-95956-25), Lock Nut Wrench 28 (782424-9), Wheel Cover (125886-2),
Inner Flange (224399-1), Lock Nut (224568-4),Side Handle (153489-2), Plastic Carrying Case (824736-5)
Two Stage Safety Paddle Switch (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy right or left handed operation
• Removable side handle can be mounted on left or right side of tool
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
7.5 A
Overall Length
10-3/4˝ (273 mm)
Net Weight
4.6 lbs (2.1 kg)
9557PB
9557PBK
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Center Wheel (1 Ea.A-95956-25), Lock Nut Wrench 28 (782424-9), Wheel Cover (123735-7), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153489-2)
Thumb Switch with Lock-On (AC/DC)
• Labyrinth construction seals motor and bearings from contamination
• Thumb switch conveniently located for operator comfort
• Removable side handle can be mounted on left or right side of tool
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
7.5 A
Overall Length
10-5/8˝ (271 mm)
Net Weight
3.5 lbs (1.6 kg)
9557NB
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Center Wheel (1 Ea.A-95956-25), Lock Nut Wrench 28 (782424-9), Lock Nut (224568-4), Inner Flange (224399-1),
Wheel Cover(123098-1), Side Handle (153504-2), Plastic Carrying Case (824736-5)
Thumb Switch with Lock-On (AC)
• Labyrinth construction seals motor and bearings from contamination
• “Zig - Zag” varnish on armature and powder coating on field to protect motor from abrasion
• Engineered for durability – double protection against dust, high quality motor and machined gears
• Ergonomic soft grip for vibration absorption and comfortable operation
• Slim housing design for easy handling and maneuverability
• Thumb switch conveniently located for operator comfort
4-1/2˝ Angle Grinder With Slim Motor Housing
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝- 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
6.0
Overall Length
10-1/2˝ ( 266 mm)
Net Weight
4.0 lbs (1.8 kg)
GA4530K
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Center Wheel (1 Ea.A-95956-25), Lock Nut Wrench 28 (782424-9), Wheel Cover (123098-1), Inner Flange (224399-1),
Lock Nut (224568-4), Side Handle (153504-2)
Two Stage Safety Paddle Switch (AC/DC)
• Re-Designed Gear Housing for enhanced shaft lock durability
• Labyrinth Construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor Winding Protection features ˝Zig-Zag˝ varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Rotatable Gear Housing can be positioned at every 90° for optimal positioning
• Removable Side Handle can be mounted on left or right side of tool
• Slim Housing Design for easy handling and maneuverability
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,000 RPM
AMPS (120V)
6.0 A
Overall Length
10-3/8˝ (265 mm)
Net Weight
4.2 lbs (1.9 kg)
GA4534
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
4-1/2˝ Depressed Centre Wheels (A-95956-25), Side Handle(153489-2), Lock Nut Wrench 28 (782424-9), Wheel Cover (123144-0),
Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
Two Stage Safety Paddle Switch (AC)
• “SJS” Technology prevents kickback if wheel jams protecting both the operator and tool
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
• Rotatable gear housing can be positioned at every 90°
• Advanced dust-proof construction
“SJS” Technology, Variable Speed,
Electronic Current Limiter
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
2,800 - 10,500 RPM
AMPS (120V)
13.0 A
Overall Length
12-1/8˝ (307 mm)
Net Weight
5.3 lbs (2.4 kg)
9564PCV
STANDARD EQUIPMENT INCLUDES:
Side Handle (153489-2), Lock Nut Wrench 28 (782424-9), Wheel Cover (123144-0), Inner Flange 45 (224399-1), Lock Nut 5/8-45 (224568-4)
Two Stage Safety Paddle Switch (AC/DC)
• "SJS" Technology prevents kickback if wheel jams protecting both the operator and tool
• Labyrinth construction seals motor and bearings from contamination
• Large paddle switch for easy operation right or left handed
• Removable side handle can be mounted on left or right side of tool
• Rotatable gear housing can be positioned at every 90°
• Advanced dust-proof construction
4-1/2˝ Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
4-1/2˝ (115 mm)
Sanding Disc
4-1/2˝ (115 mm)
Wire Cup Brush
3-1/2˝ (90 mm)
Spindle Thread
5/8˝ - 11 UNC
No Load Speed
11,900 RPM
AMPS (120V)
10.0 A
Overall Length
12-1/8˝ (307 mm)
Net Weight
5.2 lbs (2.4 kg)
9564P
“SJS” Technology
