EN5950SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (126281-9), Blade Cover (454278-1), Box Driver (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Short Shaft Style Ideal For Vertical Cutting of Tall Hedges and Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers to be operated at
any angle for maximum vertsaility
• Fixed hedge trimmer head ideal for use in vertical
cutting applications
• 23-1/4˝ double-sided blades for fast, versatile
cutting of hedges and shrubs
• Wide trigger control and soft rubber grip design for
comfortable operation
23-1/4˝ / 25.4 cc 4 Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement 25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 hp
Cutting Length 23-1/4˝ (590 mm)
Carburetor Diaphragm Type
Fuel Tank Capacity 0.6 L
Overall Length 70˝ (171 cm)
Net Weight 13.2 lbs (6.0 kg)
EN4950H
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (135784-2), Blade Cover (452328-6), Box Driver (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Long Shaft Style Ideal For Reaching Tall Hedges Or Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge
Trimmers to be operated at any angle for maximum vertsaility
• 135 °hedge trimmer head articulation (-90°- 45°)
with 13 positive stops (11.25° increments)
• Pin style angle securing system provides
added retention at positive stop angles
versus fricton securing systems
• Hedge trimmer blades fold up to
180 °to provide compact size during
transport or storage
19-1/4˝ / 25.4 cc 4 Stroke Long Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement 25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 hp
Cutting Length 19-1/4˝ (490 mm)
Carburetor Diaphragm Type
Ignition System Electronic
Fuel Tank Capacity 0.6 L
Overall Length 100-3/8˝ (255 cm)
Net Weight 15.2 lbs ( 6.9 kg)
EY2650H25H
STANDARD EQUIPMENT INCLUDES:
Chain (196142-7), 10˝ Guide Bar (165695-7), Chain Cover (452093-7), BandAssembly (125516-5), Box Driver (782233-6), Driver (783020-6),
Hex Wrench 4 (783223-2), Oil Supply, Safety Goggles (195246-2),Accessory Bag (831304-7), Starter Rope (444023-2), Spark Plug (168534-0)
Ideal for pruning and limbing in tall trees or hard
to reach areas
• Reduced fuel consumption and operating costs impact versus
competitive 2 stroke models
• Cleaner 4-stroke emissions limits environmental impact
and reduced carbon buildup in engine
• Lightweight head design for reduced operator fatigue
• Patented lubrication system enables telescopic
pole chainsaw to be used at any angle
• Decompression valve and primer
pump enable quick and easy starting
• Fully compliant with CARB Tier 3,
EPA Phase 2, EU Stage 2 exhaust
emissions regulations
10˝ / 25.4 cc 4-Stroke Pole Chainsaw
SPECIFICATIONS
Displacement 25.4 cc
Chain Pitch / Gauge 3/8˝ / . 050˝
Maximum Engine Power 0.77 Kw / 1.1 hp
Maximum Engine Speed 10,000 RPM
Cutting Length 10˝ (255 mm)
Carburetor Diaphragm Type
Fuel Tank Capacity 600 ml
Oil Tank Capacity 120 ml
Overall Length 154-1/2˝ (272 cm)
Net Weight 16 lbs ( 7.2 kg)
When QUALITY & SERVICE Counts – Choose Makita
DUM168Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Base Frame (326146-7), Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Battery Protection System provides Over-Discharge, Temperature
and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Battery Capacity Warning Light indicates low battery capacity
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
6-5/16˝ / 18V Cordless Grass Shear
SPECIFICATIONS
Battery Capacities 18V Li-Ion
No Load Speed 1,250 SPM
Cutting Width 6-5/16˝ (160 mm)
Depth Adjustment 3/8˝ / 13/16˝ / 1-3/16˝
(10 mm / 20 mm / 30 mm)
Overall Length 13-7/8˝ (353 mm)
Net Weight 2.9 lbs (1.1 kg)
Dual Blade Action
Optional Hedge
Trimmer Attachment
for DUM168Z & MU01Z
Hedge Trimmer Blades 195178-3
Hedge Trimmer Cover 195274-7
MU01Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy depth adjustment
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and
comfortable operation
Dual Blade Action
6-5/16˝ / 12V Cordless Grass Shear
SPECIFICATIONS
Battery 12V MAX (1.3 Ah) Li-Ion
No Load Speed 1,250 SPM
Cutting Width 6-5/16˝ (160 mm)
Depth Adjustment 3/8˝ / 9/16˝ / 1˝
(10 mm / 15 mm / 25 mm)
Overall Length 11-1/2˝ (292 mm)
Net Weight 2.0 lbs (0.9 kg)
Optional Hedge
Trimmer Attachment
for DUM168Z & MU01Z
Hedge Trimmer Blades 195178-3
Hedge Trimmer Cover 195274-7
Outdoor Power Equipment
HU01Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately. ShearBladeAssembly(195178-3),BladeCover(195274-7),ChipReceiverSet(195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock Off Button for added safety
7-7/8˝ / 12V Cordless Hedge Trimmer
SPECIFICATIONS
Battery 12V MAX (1.3 Ah) Li-Ion
No Load Speed 1,250 SPM
Cutting Width 7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length 18-1/8˝ (460 mm)
Net Weight 2.2 lbs (1.0 kg)
Optional Grass
Shear Attachment
for HU01Z
Grass Shear Blades 195176-7
Grass Shear Cover195269-0
Dual Blade Action
Chip Receiver Set
(Standard Equipment)
(Part No. 195278-9)
