Makita General Catalogue

170 / 180

170
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
STANDARD EQUIPMENT INCLUDES:
Tool-Kit (282-290301-H0),Two Spark Plugs (065-01402-80), Wheel Kit (110004-C), (Battery Not Included)
Electric Start
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V / 240V (30 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off, Auto
decompression / Electronic ignition, Overhead
valve for more fuel efficiency
8.2 Hours Of Continuous Operation
12,000W / 653 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current 12,000W
(100 / 50 AMP)
Rated Output Current 9,500W / 79.2 / 39.6 A
AC Voltage 60 Hz (120V / 240V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 653 cc
Max. Power 22 hp @ 3,600 RPM
Fuel Tank Capacity 44 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level 77 dB
Dimensions (L x W x H)
32.5˝ x 24.1˝ x 30.4˝
(826 mm x 611 mm x 771 mm)
Dry Weight 310.0 lbs (141 kg)
G12000R
STANDARD EQUIPMENT INCLUDES:
Tool Kit (224-90303-00), Starter Rope (20B-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20 AMP) Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V, 240V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Full power mode switch,
Low oil automatic shut-off, Auto decompression / Electronic ignition, Overhead valve for more
fuel efficiency
6.6 Hours Of Continuous Operation
7,100W / 404 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current 7,100W
(59.2 / 29.6 AMP)
Rated Output Current 5,000W / 41.6 / 20.8 A
AC Voltage 60 Hz (120V / 240V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 404 cc
Max. Power 12.5 hp @ 4,000 RPM
Fuel Tank Capacity 22 L
Continuous Operation
6.6 Hrs (at high RPM)
Noise Level 75.5 dB
Dimensions (L x W x H)
28-1/2˝ x 20-7/8˝ x 21-3/4˝
(725 mm x 530 mm x 580 mm)
Dry Weight 189.6 lbs (86 kg)
EG711A
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-JO), Starter Rope (279-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, full power mode switch,
Low oil automatic shut-off, Auto decompression / Electronic ignition,
Overhead valve for more fuel efficiency
6.8 Hours Of Continuous Operation
5,100W / 287 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current 5,100W
(42.5 / 21.3 AMP)
Rated Output Current
4,200W / 35.0 / 17.5 A
AC Voltage 60 Hz (120V / 240V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 287 cc
Engine EX30D
Max. Power 9.5 hp @ 4,000 RPM
Fuel Tank Capacity 17.8 L
Continuous Operation
6.8 Hrs. (at high RPM)
Noise Level 74 dB
Dimensions (L x W x H)
26-1/2˝ x 20˝ x 21-1/4˝
(675 mm x 570 mm x 570 mm)
Dry Weight 152.1 lbs (69 kg)
EG511A EG301A
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-JO), Starter Rope (277-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20AMP)
• GENERATOR: Full copper windings, Brushless design, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, full power mode switch,
Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for more fuel
efficiency, Recoil starter
8.2 Hours Of Continuous Operation
3,000W / 169 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current 3,000W (25 AMP)
Rated Output Current 2,400W (20 AMP)
AC Voltage 60 Hz (120V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 169 cc
Max. Power 6.0 hp @ 4,000 RPM
Fuel Tank Capacity 12.8 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level 70.5 dB
Dimensions (L x W x H)
23-5/8˝ x 16-1/2˝ x 19-3/4˝
(600 mm x 420 mm x 500 mm)
Dry Weight 103.4 lbs (47 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-J0), Starter Rope (277-50408-08), Spark Plug (065-01402-10)
Multi-Monitor LED Display
• RECEPTACLES: Duplex 120V (20AMP), Locking 120V (20AMP)
• GENERATOR: Full copper windings, Brushless design, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4-cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for
more fuel efficiency, Recoil starter
9.1 Hours of Continuous Operation
2,800W / 169 cc 4 Stroke Inverter Generator
SPECIFICATIONS
Maximum Output Current 2,800W (23.3 AMP)
Rated Output Current 2,500W / 20.8 A
AC Voltage 60 Hz (120V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 169 cc
Max. Power 6.0 hp @ 4,000 RPM
Fuel Tank Capacity 10 L
Continuous Operation
9.1 Hrs (at High RPM)
Noise Level 67 dB
Dimensions (L x W x H) 19˝ x 17˝ x 18-3/4˝
(487 mm x 432 mm x 475 mm)
Dry Weight 82.0 lbs (37.0 kg)
G2800I
STANDARD EQUIPMENT INCLUDES:
Tool Kit (33K-99001-H0), Starter Rope (284-50233-08), Spark Plug (065-01403-80)
• RECEPTACLES: Duplex 120V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4-cycle single cylinder OHC gasoline engine, Idle switch features full power
mode, Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for more fuel
efficiency, Recoil starter
• Invertor Generator restricts fluctuations: Voltage less than 3%, Frequency less than 1%, Wave distortion
less than 2.5%. Can be used to power your computer
or other sensitive equipment
3.5 Hours of Continuous Operation
1,700W / 85.8 cc 4 Stroke Inverter Generator
SPECIFICATIONS
Maximum Output Current 1,700W (14.2 AMP)
Rated Output Current 1,350W / 11.2 A
AC Voltage 60 Hz (120V)
DC Voltage 12 VDC (8.3 AMP)
Displacement 85.8 cc
Max. Power 2.4 hp @ 4,000 RPM
Fuel Tank Capacity 3.5 L
Continuous Operation
3.5 Hrs (at High RPM)
Noise Level 59 dB
Dimensions (L x W x H)
18-15/16˝ x 11/5/8˝ x 17-1/2˝
(490 mm x 295 mm x 445 mm)
Dry Weight 45.2 lbs (20.5 kg)
G1700I
Makita offers a wide variety of ACCESSORIES!
