175 / 180
Built in LED
to illuminate
tight spaces
Cordless
Power Tools
makita.ca175
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BFL081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high
volume assembly processes
Reversible
3/8˝ Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-13/16˝ (71 mm)
Height (With Battery)
3-5/8˝ (92 mm)
Length (With Battery)
17.0˝ (430 mm)
Net Weight
2.4 lbs (1.1 kg)
No Load Speed:
BFL081FZ
700 RPM
BFL121FZ
410 RPM
BFL200FZ
220 RPM
Fastening Torque:
BFL081FZ
2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL121FZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
BFL200FZ
8 - 20 Nm. (70.8 – 177 in./lbs.)
BFL200FZ
BFL121FZ
BFL080FZ BFL120FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-9/16˝ (65 mm)
Height (With Battery) 2-15/16˝ (74.0 mm)
Length (With Battery)
17˝ (430 mm)
Net Weight
2.4 lbs (1.1 kg)
No Load Speed:
BFL080FZ
450 RPM
BFL120FZ
250 RPM
Fastening Torque:
BFL080FZ
2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL120FZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
Reversible
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
3/8
˝
Cordless Impact Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-Ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Impacts Per Minute
0 – 3500 IPM
Width
2-15/16˝ (74 mm)
Height (With Battery)
8-1/2˝ (216 mm)
Length
5-5/8˝ (144 mm)
Net Weight
1.8 lbs (0.8 kg)
No Load Speed:
BTW104Z
0 – 2700 RPM
BTW074Z
0 – 2500 RPM
Fastening Torque Up To:
BTW104Z
95 Nm. (841 in./lbs.)
BTW074Z
65 Nm. (575 in./lbs.)
BTW074Z
BTW104Z
DFL400FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Cordless Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
No Load Speed
260 RPM
Fastening Torque
25 - 40 Nm.
(221 – 354 in./lbs.)
Width
2-7/8˝ (73 mm)
Height (With Battery)
4-1/8˝ (104 mm)
Length (With Battery) 20-1/16˝ (510 mm)
Net Weight
3.3 lbs (1.5 kg)
High Fastening Precision With Compact And Lightweight Design
• Automatic battery shut-off system warns operator visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or under-tightening by stopping the motor after
completing a pre-set number of impacts
• LED display panel enables number of impacts to be easily set and quickly referenced during operation
• Torque stabilization system detects remaining battery capacity to ensure consistent delivery of
torque versus impact time
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
Reversible
BFL080FZ
Anti-Kick Back Attachment
195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications
(Sold Separately)
LONGER LIFE
LESS HEAT
MORE RUN TIME
MORE WORK
Please refer to page 8 of this catalogue
