Makita General Catalogue

159 / 182

159
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
EA6100PRGE 21˝ / 60.7 cc 2-Stroke Chainsaw
21˝ / 60.7 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and Winter Operation Mode
• SAS / Stratified Air Scavenging System to comply with many exhaust emission regulations
• Easy Start / Equipped with a Spring Assisted Recoil Starter for 30% Less pulling force and Low RPM Ignition Coil providing Faster, Easier Starting
• Heavy Duty Cartridge Filter System designed for Extended Filter Life and Less Maintenance
• Touch & Stop / One Lever Control for Starting, Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening System is engineered for reducing vibration transfer to the operator
• Fuel Primer Bulb for Improved and Quicker Cold Starts
• Aggressive Large Metal Spike Bar for Safety and Hinge Action Cutting
• Half Throttle-lock start position with Easy Start for Reduced Start-Up Force
• Easy Remove Air Filter and Spark Plug Cover for quick maintenance access
SPECIFICATIONS
Displacement 60.7 cc (3.7 )
Chain Pitch / Gauge 3/8" / . 058”
Max. Engine Speed 13,800 RPM
Power Rating 3.4 kW / 4.5 hp
Fuel Tank Capacity 800 ml
Oil Tank Capacity 480 ml
Fuel / Oil Mixture 50:1
Net Weight: Dry w/o Bar & Chain 13.2 lbs (6.0 kg)
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 21˝ Guide Bar (443 053 651), Chain Cover (952 020 660),Tool Kit (957 004 002)
SAS + Easy Start
+ Winter Mode
Longlife Air Filter system
'Easy Start' Features
'Touch & Stop' one lever control
STANDARD EQUIPMENT INCLUDES:
20-21˝ Chain (523 099 072), 20˝ Guide Bar (445 050 655),
Chain Cover (952 020 660),Tool Kit (957 004 002), Starter Rope (108 164 020), Spark Plug (965 603 021)
20˝ / 72.6 cc Environment-Friendly 2-Stroke Chainsaw with Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Half Throttle-lock start position with
Decompression Valve for Reduced Start-Up Force
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal Spike Bars
for Safety and Hinge Action Cutting
• Easy Remove Air Filter and Spark Plug Cover
for quick maintenance access
• Electronic Ignition system incorporates
a Microprocessor
SLR + Decompression Valve
+ Winter Mode
20˝ / 72.6 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement 72.6 cc (4.4 )
Chain Pitch / Gauge 3/8˝ / . 058˝
Maximum Engine Speed 12,800 RPM
Power Rating 4.0 kW / 5.4 hp
Fuel Tank Capacity 750 ml
Oil Tank Capacity 420 ml
Fuel / Oil Mixture 50:1
Net Weight 13.8 lbs (6.3 kg)
EA7300PRFE
When QUALITY & SERVICE Counts – Choose Makita
EA6100
DCS5121REJ
STANDARD EQUIPMENT INCLUDES: 18˝ Chain (523 686 072),18˝ Guide Bar (445 045 631), Chain Cover (952 020 650),
Starter Rope (108 164 020), Spark Plug (965 603 021),Tool Kit (957 004 002)
18˝ / 50 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start
and Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hing
Action Cutting
• Half Throttle-lock start
position with Easy
Start for Reduced
Start-Up Force
SLR + Easy Start
+ Winter Mode
18˝ / 50 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement 50 cc (3.1 .)
Chain Pitch / Gauge .325˝ / .058˝
Maximum Engine Speed 13,800 RPM
Power Rating 2.5 kW / 3.3 hp
Fuel Tank Capacity 470 ml
Oil Tank Capacity 269 ml
Fuel / Oil Mixture 50:1
Net Weight: Dry w/o Bar & Chain
12.1 lbs (5.4 kg)
Outdoor Power Equipment
18˝ Rescue Bar
& Chain Kit
Sold Separately
(Part No. 957 415 060)
See page 160
All Makita Gasoline Powered Chainsawsnow feature
New HIGH VISIBILITY SAFETY COLOUR!
