EA4300FREC
STANDARD EQUIPMENT INCLUDES:
.325˝ Chain 18" 50G (512 484 672), 18˝ Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (419560-5), Spike Bar (346301-5),
Universal Wrench (782026-1),Torx Wrench (782025-3), Screwdriver (for CarburetorAdjustment) (783012-5), Spark Plug (0650109950)
18˝ / 43 cc Environment-Friendly 2-Stroke Chainsaw with Easy Start and
Winter Operation Mode
• SLR / Scavenging Losses Rejection Muffler
producing much Cleaner Emissions
• Easy Start / Equipped with a Spring Assisted Recoil
Starter for 30% Less pulling force and Low RPM
Ignition Coil providing Faster, Easier Starting
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Dual Mount, Aggressive Large
Metal Spike Bars for Safety and
Hing Action Cutting
Catalytic Converter Muffler
+ Easy Start + Winter Mode
18˝ / 42.4 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
42.4 cc (2.6
cu.in.)
Chain Pitch / Gauge
.325˝ / .050˝
Maximum Engine Speed 13,500 RPM
Power Rating
2.1kW / 2.9 hp
Fuel / Oil Mixture (Makita Oil)
50:1
Fuel Tank Capacity
480 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
10.8 lbs (4.9 kg)
EA4300
EA3501SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain Chain (196444-1), Chain Cover 14”-16” (419560-5), Spike Bar (346301-5),
Universal Wrench (782026-1), Starter Rope (444038-9), Spark Plug (0650109950), Screwdriver (783012-5)
16˝ / 35 cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
16˝ / 35 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
35 cc (2.1
cu.in)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 13,100 RPM
Power Rating
1.7 kW / 2.3 hp
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
290 ml
Net Weight: Dry w/o Bar & Chain
9.9 lbs (4.5 kg)
EA3201SRDB
STANDARD EQUIPMENT INCLUDES:
16˝ Guide Bar (165202-6), 16˝ Chain (196444-1), Chain Cover 16˝ (419560-5), Spike Bar (346301-5), Universal Wrench 13/16 (782026-1),
Screwdriver (783012-5), Spark Plug (0650109950), Starter Rope (444038-9)
16˝ / 32 cc Environment-Friendly 2-Stroke Chainsaw with
Intelligent Ignition Coil + Easy Start
• Intelligent Ignition Coil controls Stable Idling,
increases Output Power, protects against Engine
Overrun and enables Easier Restarting
• Toolless Chain Tensioner for quick and
easy adjustments
• Touch & Stop / One Lever Control for Starting,
Running and Shut Down Operation
• Steel Spring / Advanced Vibration Dampening
System is engineered for reducing vibration
transfer to the operator
• Fuel Primer Bulb for Improved
and Quicker Cold Starts
• Aggressive Large Metal
Spike Bar for Safety
and Hinge Action
Cutting
Intelligent Ignition Coil
+ Easy Start
16˝ / 32 cc 2-Stroke Chainsaw
SPECIFICATIONS
Displacement
32 cc (1.95
cu.in.)
Chain Pitch / Gauge
3/8˝ / .050˝
Maximum Engine Speed 12,800 RPM
Power Rating
1.35 kW / 1.8 hp
Fuel / Oil mixture
50:1
Fuel Tank Capacity
400 ml
Oil Tank Capacity
280 ml
Net Weight: Dry w/o Bar & Chain
9.4 lbs (4.2 kg)
All Makita
Gasoline Powered Chainsaws
now feature
New
HIGH VISIBILITY SAFETY COLOUR!
Intelligent Ignition Coil
+ Easy Start
DUC353Z
14˝ / 18Vx2 LXT Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
14˝ (350 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed
0-3,940 FPM (0-1 200 m/min)
Overall Length
30-1/2˝ (773 mm)
Net Weight
8.9 lbs (4.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
14" Chain (196741-5), 14" Guide Bar (165246-6), Chain Cover (419288-5),
Spike Bumper (347078-5), Oil Supply (182229-1)
makita.caDUC353Z
Brushless Outer
Motor + XPT + 3 Year
Limited Warranty
DUC353Z
14˝ / 18Vx2 LXT Cordless Chainsaw with Specialized
Battery Positioning for Optimum Balance and Control
• Fast, Variable Speed (3,940 Feet Per Minute) Equivalent to a 30 cc Gasoline Chainsaw
• Specialized 18Vx2 Battery Positioning is the Makita Industry Game Changer within the Cordless
Product line offering Premium Balance, Control and Cutting Performance
• Makita Built Outer Rotor Brushless Motor Direct Drive System for High Power & Speed
equivalent to a 30cc Gasoline Chainsaw
• XPT / eXtreme Protection Technology offers maximum protection against dust, debris
and liquids for optimal performance in extreme conditions
Unique Battery Positioning for
Optimum Performance
Brushless Outer
Motor Direct
Drive System
