165 / 182
makita.ca
165
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
EBH341U
STANDARD EQUIPMENT INCLUDES:
10˝StarBlade(B-14124),Bump&FeedTrimmerHead(B-05131),ProtectiveGuard(452259-9),TrimmerHeadProtectiveGuardAttachment
(135398-7), BoxDriver16-17(783013-3),HexWrenchM4(783202-0),HexWrenchM5(783217-7),ShoulderHarness(122906-3),
EngineOilSet,StarterRope(444018-5),SparkPlug(168534-0),ToolCover(450573-7),AccessoryBag(831304-7)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Heavy duty solid steel straight shaft
• Clean exhaust emissions and lower fuel consumption
• Equipped with ˝Swivel System˝ U-handle for
maximum operator comfort
• 40% less fuel consumption
compared to 2-stroke equivalent
Low Vibration, Extreme
Fuel Cost Savings
10˝ / 33.5 cc 4-Stroke Brush Cutter / Line Trimmer
SPECIFICATIONS
Cutting Width: 10˝ (254 mm) With Blade
16˝ (406 mm) With Line Head
Displacement
33.5 cc
Maximum Engine Power 1.07 Kw / 1.44 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.65 L
Oil Tank Capacity
0.1 L
4-Stroke Crank Case oil
10W-30
Overall Length
71-1/4˝ (181 cm)
Dry Weight
15.7 lbs (7.1 kg)
EBH253L
STANDARD EQUIPMENT INCLUDES:
Trimmer HeadAssembly (B-05125),Protective Guard (452260-4),Trimmer Head Protective GuardAttachment (135398-7),
Box Wrench 16-17 (783013-3),Hex Wrench M4 (783202-0), Hex Wrench M5 (783217-7), Shoulder Harness (125516-5),
Engine Oil Set, Starter Rope (444020-8), Spark Plug (168534-0),Accessory Bag (831304-7)
Save The Cost Of The Trimmer With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• 40% less fuel consumption compared to
2-stroke equivalent
Quiet, Low Vibration,
Extreme Fuel Cost Savings
16˝ / 24.5 cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16˝ (406 mm)
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4˝ (177 cm)
Dry Weight
11.5 lbs ( 5.2 kg)
ER2550LH
STANDARD EQUIPMENT INCLUDES:
CutterAssy (122980-1), Protective Guard (141511-7), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Engine Oil Set,
Starter Rope (444019-3), Spark Plug (168534-0),Accessory Bag (831304-7)
Makita Mini 4-Stroke Series Curved Shaft Trimmer For Professional Use
• Professional series flexible shaft for maximum durability and minimum vibration
• Wide trigger control and soft grip for
comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
• Outstanding power to weight ratio
16-1/4˝ / 24.5 cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16-1/4˝ (413 mm)
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
64˝ (163 cm)
Dry Weight
10.8 lbs (4.9 kg)
EBH253U
STANDARD EQUIPMENT INCLUDES:
9˝ Star Blade (B-14118), Shoulder Harness (122906-3), Box Driver 16-17 (783013-3), Hex Wrench M4 (783202-0), Hex Wrench M5 (783217-7),
Tool Cover (450573-7), Engine Oil Set, Starter Rope (444020-8), Spark Plug (168534-0),Accessory Bag (831304-7)
Save The Cost Of The Brush Cutter With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be used
on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• Easy starting
• 40% less fuel consumption
compared to 2-stroke equivalent
Quiet, Low Vibration,
Extreme Fuel Cost Savings
9˝ / 24.5 cc 4-Stroke Brush Cutter
SPECIFICATIONS
Cutting Width
9˝ (228 mm)
Displacement
24.5 cc
Maximum Engine Power 0.71 Kw / 0.97 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5L
Oil Tank Capacity
0.08L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4˝ (177 cm)
Dry Weight
13.0 lbs (5.9 kg)
STANDARD EQUIPMENT INCLUDES:
ProtectorAssembly (DA00000525), Protector (DA00000526),Trimmer Head (DA00000454), Shoulder Harness (DA00000456),
Socket Wrench M5 (DA00000457),Tool Kit (DA00000458), Spark Plug (965 603 021)
Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations
• Multi-positional engine
• Environment-friendly 2-stroke engine with
catalytic exhaust
• Wide trigger control and soft grip for
comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
17˝ / 25.7 cc 2-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
17˝ (430 mm)
Displacement
25.7cc
Maximum Engine Power
0.83 Kw / 1.15 hp
Carburetor
Diaphragm Type
Ignition System
Recoil
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
0.6L
Overall Length
69-3/4˝ (177 cm)
Dry Weight
10.8 lbs (4.9 kg)
EM2600L
Professional Use
When
QUALITY & SERVICE
Counts – Choose Makita
Outdoor
Power Equipment
Bump & Feed
Trimmer Head
(Standard Equipment)
(Part No. B-05131)
STANDARD EQUIPMENT INCLUDES:
Bump & FeedTrimmer Head (B-05131), Protective Guard (452259-9),Trimmer Head Protective GuardAttachment (135398-7),
Box Driver 16-17 (783013-3), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Engine Oil Set, Starter Rope (444018-5),
Spark Plug (168534-0), Shoulder Harness (125516-5),Accessory Bag (831304-7)
Makita's Most Powerful 4-Stroke Line Trimmer for Professional Applications
• Patented Lubrication System enables Makita 4-Stroke
Line Trimmer to be used on any Angle and Slopes
• MM4 Engine uses 40% Less Fuel when compared
to a 2-Stroke equivalent
• Equipped Easy Start System with
Auto Decompression for Faster
Easier Starting
• Adjustable Loop Handle with
Extension Bar for Optional Brush
Cutter Operation
• Clean Exhaust Emissions and
Lower Fuel Consumption
Heavy Duty Inner
Solid Steel Straight
Shaft Design
16˝ / 33.5 cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width: 10˝ (254 mm) With Blade
16˝ (406 mm) With Line Head
Displacement
33.5 cc
Maximum Engine Power 1.07 Kw / 1.44 hp
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.65 L
Oil Tank Capacity
0.1 L
4-Stroke Crank Case oil
10W-30
Overall Length
71-1/4˝ (181 cm)
Dry Weight
14.8 lbs (6.7 kg)
EBH341L
Low Vibration, Extreme
Fuel Cost Savings
