176 / 182
MANUFACTURING & ASSEMBLY
makita.ca176
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DFL082FZ
DFL122FZ BFL202FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Designed and manufactured to withstand
high volume assembly processes
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-15/16˝ (74 mm)
Height (With Battery)
3-7/8˝ (98 mm)
Length (With Battery)
16-5/8˝ (422 mm)
Net Weight
2.6 lbs (1.2 kg)
No Load Speed:
DFL082FZ
700 RPM
DFL122FZ
410 RPM
BFL202FZ
220 RPM
Fastening Torque:
DFL082FZ
2 - 8 Nm. (18 – 71 in./lbs.)
DFL122FZ
5 - 12 Nm. (44 – 106 in./lbs.)
BFL202FZ
8 - 20 Nm. (71 – 177 in./lbs.)
Reversible
BFT040FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for
outstanding ergonomics
• On board LED and audible signal informs user of
successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand
high volume assembly processes
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-9/16˝ (65 mm)
Height (With Battery)
10-3/4˝ (274 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.2 lbs (1.0 kg)
No Load Speed:
BFT040FZ
950 RPM
BFT080FZ
540 RPM
BFT122FZ
320 RPM
Fastening Torque:
BFT040FZ
5-12 Nm. (44.3 – 106 in./lbs.)
BFT080FZ
3 - 8 Nm. (26.6 – 70.8 in./lbs.)
BFT122FZ
5-12 Nm. (44.3 – 106 in./lbs.)
Reversible
BFT122FZ
BFT080FZ
BFT081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly pocesses
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-13/16˝ (71 mm)
Height (With Battery)
9-7/8˝ (251 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.2 lbs (1.0 kg)
No Load Speed:
BFT081FZ
700 RPM
BFT123FZ
390 RPM
Fastening Torque:
BFL301RZ
3 - 8 Nm. (26.6 – 70.8 in./lbs.)
BFL402RZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
BFT123FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for
outstanding ergonomics
• On board LED and audible signal informs user
of successful rundown
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-15/16˝ (74 mm)
Height (With Battery)
9-7/8˝ (250 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.4 lbs (1.1 kg)
No Load Speed:
DFT022FZ
700 RPM
DFT044FZ
950 RPM
BFT084FZ
780 RPM
DFT126FZ
410 RPM
Fastening Torque:
DFT022FZ
0.5 - 2 Nm. (4 - 18 in./lbs.)
DFT044FZ
1 - 4 Nm. (8.9 - 35 in./lbs.)
BFT084FZ
3 - 8 Nm. (27 - 71 in./lbs.)
DFT126FZ
5 - 12 Nm. (44 - 106 in./lbs.)
Makita offers a wide variety of
ACCESSORIES!
DFT044FZ
DFT126FZ
BFT084FZ
DFT022FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Lock Nut (457530-6)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weightand size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-13/16˝ (72 mm)
Height (With Battery)
9-3/4˝ (249 mm)
Length (With Battery)
6-1/4˝ (159 mm)
Net Weight
1.8 lbs (0.8 kg)
No Load Speed:
DFT023FMZ
400 - 1,300 RPM
DFT045FMZ
150 - 900 RPM
Fastening Torque:
DFT023FMZ
0.5 - 2 Nm. (4 - 18 in./lbs.)
DFT045FMZ
1 - 4 Nm. (9 - 35 in./lbs.)
DFT045FMZ
DFT023FMZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
USB Cable (661432-2),TorqueAdjustmentTool (765027-4), Ring 25 (424977-9)
Programmable Speed Control For Maximum Fastening Precision And Accuracy
• Precise torque control consistently delivers repeatability of +/- 10%
• Programmable speed control enables user to control speed of hard or soft joints or production
time using USB / PC connection
• Brushless DC motor with high power to weightand size ratio
• On board LED and audible signal informs user of successful run down
• Battery capacity warning light indicates ideal time
to recharge battery
Programmable
Speed Control,
Reversible
1/4˝ Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-13/16˝ (72 mm)
Height (With Battery)
10˝ (254 mm)
Length (With Battery)
7-1/2˝ (190 mm)
Net Weight
2.3 lbs (1.0 kg)
No Load Speed:
DFT085FMZ
150 - 900 RPM
DFT127FMZ
100 - 600 RPM
Fastening Torque:
DFT085FMZ
3 - 8 Nm. (27 - 71 in./lbs.)
DFT127FMZ
5 - 12 Nm. (44 - 106 in./lbs.)
DFT127FMZ
DFT085FMZ
