HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Direct Connect Battery Converter
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light
indicates approximate remaining
battery power for each battery
• Transport Wheels enable easy
movement around the work site
and can be folded upright
when not in use
13-3/4˝ / 18Vx2 LXT Cordless Cultivator
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4˝ / 8-7/8˝ (350 / 225 mm)
Tine Diameter
9-5/8˝ (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47˝x 19-1/4˝x 39-1/4˝
(119 cm x 49 cm x 100 cm)
Net Weight
48.5 lbs (22.2 kg)
When
QUALITY & SERVICE
Counts – Choose Makita
DUM168Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Base Frame (326146-7), Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Battery Protection System provides Over-Discharge, Temperature and Current
Protection for enhanced performance, battery cycle life and overall battery life
• Battery Capacity Warning Light indicates low battery capacity
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy
depth adjustment
• Tool-less Blade Changing System enables simple and easy
blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
6-5/16˝ / 18V LXT Cordless Grass Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
1,250 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
3/8˝ / 13/16˝ / 1-3/16˝
(10 mm / 20 mm / 30 mm)
Overall Length
13-7/8˝ (353 mm)
Net Weight
2.9 lbs (1.1 kg)
Dual Blade Action
Outdoor
Power Equipment
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers
for easier operation, maximum versatility and operator safety
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle life
and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
18V LXT Cordless Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2˝ (50 mm)
Wood (12" Blade)
2˝ (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2˝ (13 mm)
Overall Length
15-5/8˝ (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
For
ACCESSORIES
see pages 70 - 71
4-STROKE ENGINE MAINTENANCE KIT FOR
HEDGE TRIMMERS, SPLIT SHAFT ENGINE UNIT
& POLE CHAINSAW
Description For Engine No.
For Models
Contents
Part No.
Engine
Maintenance
Kit
EH026
EN4950H, EN5950SH
EX2650LH
EY2650H25H
Air Filter x 2
Fuel Filter
Spark Plug
197680-2
197680-2
EN5950SH
UH201DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UH201DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet(198409-9),BladeCover(195274-7),ChipReceiverSet(198402-3)
HU01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly(195178-3),BladeCover(195274-7),ChipReceiverSet(195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8˝ / 12V LXT Cordless Hedge Trimmers
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length
19-7/8˝ (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ or HU01Z
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
HU01Z
12V MAX (1.3 Ah) Pod
UH201DZ
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly(195176-7),BladeCover(452055-5),GrassCatcher(457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16˝ / 12V LXT Cordless Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
5/8˝ / 13/16˝ / 1˝
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8˝ (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
ChipReceiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
Optional Hedge
Trimmer Attachment
for DUM168Z
Shear BladeAssembly
198409-9
ChipReceiver Set
198405-3
Blade Cover
195274-7
UH201DZ:
12V MAX CXT Slide
HU01Z:
12V MAX (1.3 Ah) Pod
HU01Z
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
