DFL300FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately. Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝ (9.5 mm)
Width 2-7/8˝ (73 mm)
Height (With Battery) 4-1/8˝ (104 mm)
No Load Speed 400 RPM
Fastening Torque
16 - 30 Nm. (142 – 266 in./lbs.)
Length (With Battery) 19-15/16˝ (506 mm)
Net Weight 3.1 lbs (1.4 kg)
BFL081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high
volume assembly processes
Reversible
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery 12V Ni-MH
Capacity (Driving Shank)
Square 3/8˝ (9.5 mm)
Width 2-13/16˝ (71 mm)
Height (With Battery) 3-5/8˝ (92 mm)
Length (With Battery) 17.0˝ (430 mm)
Net Weight 2.4 lbs (1.1 kg)
No Load Speed:
BFL081FZ 700 RPM
BFL121FZ 410 RPM
BFL200FZ 220 RPM
Fastening Torque:
BFL081FZ 2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL121FZ 5 - 12 Nm. (44.3 – 106 in./lbs.)
BFL200FZ 8 - 20 Nm. (70.8 – 177 in./lbs.)
BFL200FZ BFL121FZ BFL080FZ BFL120FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Precise Torque Angle Wrenches
SPECIFICATIONS
Battery 9.6V Ni-MH
Capacity (Driving Shank)
Square 3/8˝ (9.5 mm)
Width 2-9/16˝ (65 mm)
Height (With Battery) 2-15/16˝ (74.0 mm)
Length (With Battery) 17˝ (430 mm)
Net Weight 2.4 lbs (1.1 kg)
No Load Speed:
BFL080FZ 450 RPM
BFL120FZ 250 RPM
Fastening Torque:
BFL080FZ 2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL120FZ 5 - 12 Nm. (44.3 – 106 in./lbs.)
Reversible
When QUALITY & SERVICE Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
3/8 ˝ Impact Wrench
SPECIFICATIONS
Battery Capacities 14.4V Li-Ion
Capacity (Driving Shank)
Square 3/8˝ (9.5 mm)
Impacts Per Minute 0 – 3500 IPM
Width 2-15/16˝ (74 mm)
Height (With Battery) 8-1/2˝ (216 mm)
Length 5-5/8˝ (144 mm)
Net Weight 1.8 lbs (0.8 kg)
No Load Speed:
BTW104Z 0 – 2700 RPM
BTW074Z 0 – 2500 RPM
Fastening Torque Up To:
BTW104Z 95 Nm. (841 in./lbs.)
BTW074Z 65 Nm. (575 in./lbs.)
BTW074Z BTW104Z
DFL400FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately. Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝ Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities 14.4V Li-ion
Capacity (Driving Shank)
Square 3/8˝ (9.5 mm)
No Load Speed 260 RPM
Fastening Torque 25 - 40 Nm.
(221 – 354 in./lbs.)
Width 2-7/8˝ (73 mm)
Height (With Battery) 4-1/8˝ (104 mm)
Length (With Battery) 20-1/16˝ (510 mm)
Net Weight 3.3 lbs (1.5 kg)
High Fastening Precision With Compact And Lightweight Design
• Automatic battery shut-off system warns operator visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or under-tightening by stopping the motor after
completing a pre-set number of impacts
• LED display panel enables number of impacts to be easily set and quickly referenced during operation
• Torque stabilization system detects remaining battery capacity to ensure consistent delivery of
torque versus impact time
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
Anti-Kick Back Attachment 195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications(Sold Separately)
Reversible Reversible
Anti-Kick Back Attachment 195620-4
• Prevents harmful kick back from being transmitted to operator during
high-torque fastening applications (Sold Separately)
LONGER LIFE
LESS HEAT
MORE RUN TIME
MORE WORK
Please refer to page 8 of this catalogue
