Makita General Catalogue

27 / 182

Cordless Power Tools
27
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
Ideally Suited For Concrete Footings And Wall Construction
• Multi-Directional Trigger enables operation from two directions for increased maneuverability
• Protective Battery and Switch Covers prevent damage due to contamination
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Vibrations Per Minute 12,500 VPM
Vibrator Diameter 1˝ (2.5 cm)
Shaft Length 94-1/2˝ (240 cm)
Overall Length 105-1/2˝ (268 cm)
Net Weight 11.5 lbs (5.2 kg)
DVR850RFE, DVR850Z, DVR450RFE, DVR450Z, DVR350RFE, DVR350Z
Concrete Vibrators
DVR850RFE
STANDARD EQUIPMENT INCLUDES:
DVR850RFE: Two 18V (3.0Ah) Li-Ion Batteries
w/ Charge Level Indicator BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8),
FlexibleAssembly (126208-9), Plastic Carrying Case (141481-0)
DVR850Z: Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126208-9)
DVR850Z
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Vibrations Per Minute 13,000 VPM
Vibrator Diameter 1˝ (2.5 cm)
Shaft Length 47-1/4˝ (120 cm)
Overall Length 58-1/2˝ (148 cm)
Net Weight 7.7 lbs (3.5 kg)
DVR450RFE
STANDARD EQUIPMENT INCLUDES:
DVR450RFE: Two 18V (3.0Ah) Li-Ion Batteries
w/ Charge Level Indicator BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8),
FlexibleAssembly (126206-3), Plastic Carrying Case (141481-0)
DVR450Z: Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126206-3)
DVR450Z
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Vibrations Per Minute 13,000 VPM
Vibrator Diameter 1˝ (2.5 cm)
Shaft Length 31-1/2˝ (80 cm)
Overall Length 42-3/4˝ (108 cm)
Net Weight 6.6 lbs (3.0 kg)
DVR350RFE
STANDARD EQUIPMENT INCLUDES:
DVR350RFE: Two18V(3.0Ah)Li-IonBatteries
w/ChargeLevelIndicatorBL1830B(194205-3),Rapid
Charger(DC18RC),BatteryCover(450128-8),Flexible
Assembly(126207-1),PlasticCarryingCase(141481-0)
DVR350Z: Tool Only. Batteries and Charger
Sold Separately. FlexibleAssembly (126207-1)
DVR350Z
DCG180ZC
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartidges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360 °rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size:
800 ml Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/8"
(480 mm x 108 mm x 281 mm)
Net Weight 4.6 lbs (2.1 kg)
DCG180RFEB DCG180ZB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB: Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator BL1830B
(194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8), Nozzle (454226-0),
Rubber Ring (424547-4), PistonAAssembly (142071-2), Piston CAssembly (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
DCG180ZB: Tool Only. Batteries and Charger Sold Separately.Nozzle (454226-0),
Rubber Ring (424547-4), PistonAAssembly (142071-2), Piston CAssembly (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise
Application of Caulking and Sealants
Accepts Standard 600 ml Cartidges, Sausage Packs
and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on
caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set
maximum dispensing speed while the variable
speed trigger enables fine adjustment for maximum
control and precision in a wide range of applications
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size: 600 ml Cartridge
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4˝ x 4-1/4˝ x 11-1/8˝
(538 mm x 108 mm x 281 mm)
Net Weight 5.9 lbs (2.7 kg)
DCG180RFE DCG180Z
STANDARD EQUIPMENT INCLUDES:
DCG180RFE: Two18V(3.0Ah)Li-IonBatteriesw/Charge
LevelIndicator BL1830B(194205-3),RapidCharger(DC18RC),Battery
Cover(450128-8),SafetyGoggle(195246-2),ToolBag(831278-2)
DCG180Z: Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartidges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360 °rotating tube tray allows
operator to adjust positioning
based on materials or application
• Overload protection feature with
warning light prevents motor
burnout caused by overloading
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Max. Pushing Force 1,100 lb (5,000 N)
Compatible Sealant Size
300 ml Cartridge
Dimensions (L x W x H)
15-7/8˝ x 4-1/4˝ x 11-1/8˝
(404 mm x 108 mm x 281 mm)
Net Weight 4.8 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
When QUALITY & SERVICE Counts – Choose Makita
Anti-Drip Function,
Variable Speed
Anti-Drip Function, Variable Speed
DVR350RFE
Battery
Cover
DUB183Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Long Nozzle (TP00000199)
Unique Extended Nozzle Design for Optimum Operation
• Unique Extended Nozzle Design for Optimum Operation directs Air Flow Angle for Blowing / Sweeping
Debris, Grass Clipping, Leaves etc. from Driveway's, Sidewalks and more.
• Low / Medium / High Air Volume Settings with Variable Speed Control within Each Setting
• Ergonomic Soft Rubber Grip design for Vibration Absorption and Comfortable Operation
• Anti-static design to prevent buildup of Static Electricity
• Converts to Vacuum quickly and easily
• Light Weight Design for Reduced Operator Fatigue
Low / Medium / High
Air Volume Settings
Blower / Sweeper
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Maximum Air Volume 92 CFM (2.6 m3/min)
Maximum Air Velocity 116 MPH (52 m/sec)
No Load Speed 0 - 18,000 RPM
Overall Length 33-1/4˝ (845 mm)
Net Weight 2.9 lbs (1.3 kg)
