Makita General Catalogue

Cordless

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

DUH523Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Blade Cover (453723-3), Shear Blade Complete Set (195846-8)

Designed for Maximum Versatility and Ease of Operation

• Battery Protection System provides Over-Discharge, Temperature and Current Protection

for enhanced performance, battery cycle life and overall battery life

• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly

reduced vibration transmission to operator

• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting

• Tool-less Blade Changing System enables simple and easy blade changes

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

22˝ Hedge Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Strokes Per Minute (min-1)

1,350 SPM

Cutting Length

22˝ (560 mm)

Maximum Cutting Thickness

15/32˝ (12 mm)

Overall Length

38˝ (96 cm)

Net Weight

6.0 lbs (2.7 kg)

Dual Blade Action

DUC122Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

4-1/2˝ Chain (791284-8), 4-1/2˝ Guide Bar (158476-6), Chain Cover (416311-7),

Chain File (744003-1), Oil Supply

18V Handle Mount Battery Position

• Compact design enables maximum operator

maneuverability and versatility

• Hand guard protects operators hand

during operation

• Lock-off button prevents accidental startup

• Electric brake stops chain within 0.5 seconds

for added safety

• Tip guard prevents kickback for maximum

operator safety

• Tool-less chain tension adjustment for

quick and easy adjustment on the jobsite

• Automatic chain oiler

• Metal lanyard hook enables quick

attachment to lanyard during climbing

or bucket operations

• Ergonomic soft rubber grip

design for vibration

absorption and comfortable

operation

4-1/2˝ Chainsaw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Guide Bar Length

4-1/2˝ (115 mm)

Chain Pitch / Gauge

1/4˝ / .050˝

Chain Speed

980 FPM (300 m/min)

Overall Length

16-5/8˝ (422 mm)

Net Weight

4.2 lbs (1.9 kg)

DCL500Z

Cyclone Vacuum Cleaner (250 ml)

High Efficiency, Portable Cyclone Vacuum Cleaner

• Removable Cyclonic Dust Canister separates coarse and fine dust to ensure expelled air is

virtually dust free

• Filter offers maximum performance for residential and commercial applications

• Filter Cleaning Feature clears particulate and debris from clogged filter to maximize filter efficiency and

maintain suction power

• LED filter cleaning and Battery

Capacity Warning Lights

indicate ideal time to clean filter

or recharge battery

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Container Capacity

250 ml (8.4 oz)

Continuous Use:

Approx. 20 minutes (High) with BL1850B

Approx. 50 minutes (Low) with BL1850B

Maximum Air Flow

46 CFM

Power

75 W (High) / 25 W (Low)

Static Water Lift

26˝ (66 cm)

Overall Length

12-5/8˝ (32 cm)

Net Weight

7.1 lbs (3.2 kg)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Cup FilterAssembly (HEPAFilter) (SH00000027), PSuction HoseAssembly

(SH00000034), Floor NozzleAssembly (SH00000058), Screw PipeAssembly (SH00000060), Hose Hook (SH00000041),

Turbine Crevice Nozzle (SH00000042), Shoulder Harness (166124-3), Cleaning Brush (SH00000032)

2-Speed

DCL182Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1),

Sash Nozzle Holder (451245-7), Paper Filter Set 5/Pk (194566-1)

Battery Protection System Provides Over-Discharge, Temperature &

Current Protection For Enhanced Performance & Battery Cycle Life

• Push button Air Volume Selection (High / Low settings)

• Improved front cover opens with push button for easier access

• On board Sash Nozzle Storage

• Floor Nozzle Swivel Joint design keeps vacuum head

close to surface and enables 360º rotation for

easy high-reach cleaning

2-Speed

Vacuum Cleaner (330 ml)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Container Capacity

330 ml (11.5 oz)

Continuous Use:

Approx. 33 minutes (High) with BL1850B

Approx. 66 minutes (Low) with BL1850B

Maximum Air Flow:

37.8 CFM (High)

27.2 CFM (Low)

Power

30 W (High) / 11 W (Low)

Static Water Lift

15-3/4˝ (40 cm)

Overall Length

39-1/2˝ (100 cm)

Net Weight

2.0 lbs (0.98 kg)

DUR181Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Nylon Cord (195864-6), Bump & Feed Spool Set (195858-1),

Shoulder Harness (125516-5), Safety Cover (453353-0),

Safety Goggles (195246-2)

Well Balanced Design With Fully Adjustable Features To Suit Any Operator

• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease

of operation when trimming around obstacles

• Telescopic Shaft adjusts quickly and easily to suit any operator

• Lock-Off Safety Lever prevents accidental start up

• Battery Capacity Warning Light indicates low battery capacity

10-1/4˝ Line Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

7,800 RPM

Cutting Width

10-1/4˝ (260 mm)

Overall Length

56-1/2˝ (143 cm)

Net Weight

5.5 lbs (2.5 kg)

For

ACCESSORIES

see pages 161 - 162

For

ACCESSORIES

see pages 166 - 167

When

QUALITY & SERVICE

Counts – Choose Makita

Replacement Nylon

Cutting Line 195864-6 (49')

or 195861-2 (98')

180°

Trimmer Head

rotates 180°

to enable easy

edge trimming

HEPA

filter

DUR187LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump & FeedTrimmer Head (198385-7), Shoulder Harness (125516-5),

Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7), Protective Guard (457324-9)

Lightweight and Powerful with Low Noise Level suitable for use in

Residential Areas and Public Spaces

• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work

• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool

Usage to Harsh Environments and Provides Longer Tool Life

• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during

heavy-Duty cutting for Maximum Efficiency and Performance

• Battery Protection System provides Over-Discharge,Temperature and

Circuit Protection for Enhanced Performance, and Overall Battery Life

11-3/4˝ Line Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed 4,000 / 5,000 / 6,000 RPM

Cutting Width

11-3/4˝ (300 mm)

Overall Length

70-1/2˝ (179.1 cm)

Net Weight

6.0 lbs (2.8 kg)

Brushless / ADT / XPT

Battery Protection System

For

ACCESSORIES

see pages 166 - 167

3 Speed,

Reversible

Unique Carry or

Pull Design

18V Compact

Design
