DUB182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (132025-7),
Dust Bag (122814-8)
Low / Medium / High Air Volume Settings
• Variable Speed Control within each speed setting
• Anti-Static Design to prevent buildup of static electricity
• Converts to Vacuum quickly and easily
• Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
Blower / Vacuum
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Volume 92 CFM (2.6 m
3
/min)
Maximum Air Velocity 179 MPH (80 m/sec)
Maximum Air Pressure
5.4 kpa (550 mm H
2
O)
No Load Speed
0 - 18,000 RPM
Overall Length
20-3/4˝ (525 mm)
Net Weight
2.9 lbs (1.3 kg)
Variable Speed
Optional Long Nozzle
with Curved End
Sold Separately
(Part No. TP00000199)
DVC350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly(132025-7),DustBag
(122918-6),HoseComplete28-2.5M(140456-6),ShoulderHarness(166094-6),FrontCuff(417766-9)
Portable & Versatile Vacuum Cleaner
• Push Button Air Volume Selection
(High / Low Settings)
• Shoulder Strap for operator convenience
• Can be converted into a
blower by attaching
nozzle assembly
Vacuum Cleaner (3.0 L)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
3.0 L (0.7 Gal)
Continuous Use: Approx. 21 minutes (High) with BL1850B
Approx. 42 minutes (Low) with BL1850B
Maximum Air Flow
120 CFM
Maximum Air Speed
308 ft./s (94 m/s)
Power
50 W (High) / 15 W (Low)
Static Water Lift
22˝ (56 cm)
Overall Length
15-7/8˝ (40 cm)
Net Weight
3.5 lbs (1.6 kg)
DCL180ZX
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
NozzleAssembly(123488-8),
SashNozzle(451243-1),Pipe(451244-9),SashNozzleHolder(451245-7),
ClothFilter(443060-3),NylonPre-Filter(451208-3)
Easy To Empty, See-through Dust & Debris
Collection Canister Minimizes Downtime
& Maximizes Vacuuming Efficiency
•
2 Stage Nylon and Cloth filter
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design keeps
vacuum head close to surface and
enables 360º rotation for easy
high-reach cleaning
Vacuum Cleaner (650 ml)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
650 ml (21.9 oz)
Continuous Use Approx. 33.3 minutes with BL1850B
Maximum Air Flow
46 CFM
Power
30 W
Static Water Lift
14-1/2˝ (36 cm)
Overall Length
39-5/16˝ (99 cm)
Net Weight
1.4 lbs (0.6 kg)
CORDLESS VACUUM CLEANER
TOOLS & ADAPTERS
Tool Model
Tool Adapter
Front Cuff 22
417765-1
Front Cuff 24
195546-0
Front Cuff 38
417766-9
Front Cuff 22
417765-1
Front Cuff 24
195546-0
Front Cuff 38
417766-9
DHS711PF2 / Z
196843-7
•
–
–
•
•
•
DHS680Z
196952-2
•
•
–
–
•
•
DSS611RFE / Z
P-80012
•
–
–
•
•
•
DJV181RME / Z
DJV182RME / Z
126331-0
•
•
–
–
•
•
DJV180RFE / Z
P-80020
•
–
–
•
•
•
DTM50ZKX1
195965-0
•
–
–
•
•
•
DTM51ZKX7
196765-1
•
–
–
•
•
•
DPJ180Z
No Adapters
Required
–
•
–
–
•
•
•
DCO180Z
P-80010
•
–
–
•
•
•
DSD180Z
No Adapters
Required
–
•
–
–
•
•
•
DBO180Z
No Adapters
Required
–
•
–
–
•
•
•
DHR202RFE / Z, DHR241RFE / Z
DHR242RMEV, DHR263PF2 / Z
DHR264Z
P-80015
•
–
–
•
•
•
DKP180Z
451329-1
–
–
•
–
–
•
DLS714Z
No Adapters
Required
–
–
–
•
–
–
•
DLS713Z
No Adapters
Required
–
–
–
•
–
–
•
DVC861
DVC260
DVC350
2 Speed
