11 / 40
When QUALITY Counts - ChooseMakita
Outdoor
Power Equipment
CORDLESS
POWER
ELECTRIC
POWER
Chainsaw
UC4051A
16" Bar
SPECIFICATIONS DUC302Z
DUC254Z
DUC122Z
Battery
Capacities
Two 18V Li-Ion
18V Li-Ion
Guide Bar Length
12" (30 cm)
10" (25 cm)
4-1/2" (11.5 cm)
Chain Pitch / Gauge
3/8" / 0.043"
1/4" / .050"
Chain Speed
1,650 FPM
(500 m / min)
4,720 FPM
(1,440 m / min)
980 FPM
(300 m / min)
Overall Length
23-5/8" (60 cm)
19" (48 cm)
16-5/8" (42.2 cm)
NetWeight
7.7 lbs (3.5 kg) 5.8 lbs (2.6 kg) 4.2 lbs (1.9 kg)
SPECIFICATIONS UC4051A UC3551A
Chain Pitch /
Gauge
3/8" / .050"
Chain Speed
2,900 FPM
Chain Oil Tank
Capacity
200 ml
AMPS (120V)
14.5 A
Overall Length
19-7/8" (50.5 cm)
NetWeight
12.3 lbs
(5.6 kg)
12.1 lbs
(5.5 kg)
Cordless Chainsaw
Extension Handle
(for model DUC122Z)
195595-7
Cordless Chain
Saw not included
6-1/2′ – 9-1/2′
of added reach!
Ideal for pruning and limbing in
hard to reach trees
9
ACCESSORIES
See pages 34-35 for more
CHAINSAWACCESSORIES
n QUALITY& SERVICE Counts – ChooseM kita
• Compact design enables maximum
operator maneuverability and versatility
• Hand guard protects operators hand
during operation
• Lock-off button prevents
accidental startup
• Electric brake stops chain within
0.5 seconds for added safety
• Tip guard prevents kickback for
maximum operator safety
• Tool-less chain tension adjustment for
quick and easy adjustment on the jobsite
• Tool-less chain tension adjustment for quick
and easy adjustment on the jobsite
• Soft start feature gradually increases speed
to eliminate start up shock
• Electronic current limiter prevents motor
burnout due to overloading
• Electric brake for increased operator safety
• Automatic chain oiler maintains constant
oil delivery regardless of temperature or
oil viscosity
• Increased oil tank capacity enables longer
operating time between refills
• Variable speed control by trigger
• Soft start for motor protection
• Electric chain brake
• Kickback brake
• Chain oil adjustment
• Oil Capacity Display window
• Brushless motor
• Compact & Lightweight.
• Captive nuts: prevent loss of nut when
removing sprocket cover to replace
guide bar or saw chain
• Hanging hook
• Battery capacity warning light indicates
ideal time to recharge battery
• Lock-off button prevents
accidental startup
• Inertia chain brake provides maximum
operator safety if kickback occurs
• Tool-less chain tension adjustment for
quick and easy adjustment on the jobsite
• Automatic chain oiler
• Metal lanyard hook enables quick
attachment to lanyard during climbing
or bucket operations
18VChainsaw
DUC122Z
Tool only. Battery & charger sold separately.
(Also available with Battery and Charger
DUC122SF. See makita.ca)
Soft start +
Electronic current limiter
+ Electric brake
18V Top Handle
Chainsaw
DUC254Z
Tool only. Battery & charger sold separately.
18Vx2 Chainsaw
DUC302Z
Tool only. Battery & charger sold separately.
12" Bar
XPT / eXtreme
Protection
Technology
4-1/2" Bar
18V Compact
design
10" Bar
Chainsaw
UC3530A
14" Bar
UC4051A
