Outdoor Power Equipment Catalogue

8 / 40

• Heavy Duty Cartridge Filter System
designed for Extended Filter Life and
Less Maintenance
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Bar & Chain Fasteners remain fixed to
cover when loosened
• Easy Remove Air Filter and Spark Plug
Cover for quick maintenance access
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Dual Mount, Aggressive Large Metal Spike
Bars for Safety and Hinge Action Cutting
SAS + Easy start
+ Winter mode SLR + Easy start
+ Winter mode
• Heavy Duty Cartridge Filter System
designed for Extended Filter Life and
Less Maintenance
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Aggressive Large Metal Spike Bar for
Safety and Hinge Action Cutting
SAS + Easy start
+ Winter mode
• Easy Remove Air Filter and Spark Plug
Cover for quick maintenance access
• Steel Spring / Advanced Vibration
Dampening System is engineered for
reducing vibration
• Dual Mount, Aggressive Large Metal
Spike Bars for Safety and Hinge
Action Cutting
SLR + Decompression
Valve + Winter mode
55.6CC Chainsaw
EA5600FREE
50CC Chainsaws
DCS5121REJ
EA5000PREL
60.7CC Chainsaw
EA6100PRGE
72.6CC Chainsaw
EA7300PRFE
78.5CC Chainsaw
EA7900PRFE
2-STROKE POWER
CHAINSAWS
ACCESSORIES
Chainsaw Chain
Chainsaw Bar 18" Rescue Bar & Chain
(for EA7300PRFE)
Safety Helmet
(Complete)
Chainsaw Files (12 Pack)
SPECIFICATIONS EA7900PRFE EA7300PRFE EA6100PRGE EA5600FREE DCS5121REJ EA5000PREL
Displacement 78.5cc (4.8 cu.in.) 72.6cc (4.4 cu.in.) 60.7cc (3.7 cu.in.) 55.6cc (3.4 cu.in.) 50cc (3.1 cu.in.)
Chain Pitch / Gauge 3/8" / .058" .325" / .058"
MaximumEngine Speed 12,800 RPM 13,800 RPM
Power Rating 4.4 kW / 5.7 HP 4.0 kW / 5.4 HP 3.4 kW / 4.5 HP 3.0 kW / 3.9 HP 2.5 kW / 3.3 HP 2.8 kW / 3.9 HP
Fuel Tank Capacity 750 ml 800 ml 570 ml 470 ml
Chain Oil Tank Capacity 420 ml 480 ml 320 ml 269 ml 270 ml
Fuel / Oil Mixture 50:1 Synthetic
NetWeight Dry
Without Bar And Chain 14.7 lbs (6.7 kg) 13.8 lbs (6.3 kg) 13.2 lbs (6.0 kg) 12.8 lbs (5.8 kg) 12.1 lbs (5.4 kg) 11.9 lbs (5.4 kg)
All Makita Gasoline Powered Chainsaws now feature
20" Bar
18" Bar 18" Bar 21" Bar
6
