Outdoor Power Equipment Catalogue

When QUALITY Counts - ChooseMakita

Outdoor

Power Equipment

• Easy Remove Air Filter and Spark

Plug Cover for quick maintenance access

• Aggressive Large Metal Spike Bar

for Safety and Hinge Action Cutting

• Fuel Primer Bulb for Improved

and Quicker Cold Starts

• Easy Remove Air Filter and Spark Plug Cover for quick maintenance access

• Steel Spring / Advanced Vibration Dampening System is engineered for

reducing vibration transfer to the operator

• Aggressive Large Metal Spike Bar for Safety and Hinge Action Cutting

• Fuel Primer Bulb for Improved and Quicker Cold Starts

• Aggressive Large Metal Spike Bar for Safety and Hinge Action Cutting

• Half Throttle-lock start position with Easy Start for Reduced Start-Up Force

• External Access Holes allow easy Carburetor Adjustment

• Stratified Air Scavenging engine for lower

emissions and improved fuel efficiency

• "Tool-less" chain tensioning for quick and

convenient chain adjustment

• Touch & Stop single lever control shuts off

engine with just a touch

SAS + Easy start

+ Winter mode

Catalytic converter

muffler + Easy start

+ Winter mode

Chainsaw

EA3501SRDB

Chainsaw

EA3201SRDB

35.2

Chainsaw

EA3601FRDB

42.4

Chainsaw

EA4300FREC

New

HIGH VISIBI

SAFETY COLOUR!

18" Bar

2-STROKE

POWER

See pages 34-35 for more

CHAINSAWACCESSORIES

All Makita 2-stroke engines

require the use of

Synthetic

Engine Oil with Fuel

Stabilizer

for long engine life

ACCESSORIES

Intelligent ignition coil

controls stable idling,

increases output power, protects against

engine overrun and enables easier restarting

Easy start / equipped

with a spring assisted

recoil starter for 30% less pulling force

and a low RPM ignition coil providing

faster, easier starting

Safety

Pants

Chainsaw

Chaps

Chainsaw

Case

Chainsaw

Files Sets

SPECIFICATIONS EA4300FREC EA3601FRDB EA3501SRDB EA3201SRDB

Displacement

42.4cc (2.6 cu.in.)

60.7cc (3.7 cu.in.)

35cc (2.1 cu.in)

32cc (1.95 cu.in.)

Chain Pitch / Gauge

.325" / .050"

3/8" / .050"

MaximumEngine Speed

13,500 RPM

13,100 RPM

12,800 RPM

Power Rating

2.1kW / 2.9 HP

1.7 kW / 2.4 HP

1.7 kW / 2.3 HP

1.35 kW / 1.8 HP

Fuel Tank Capacity

480 ml

310 ml

400 ml

Chain Oil Tank Capacity

280 ml

260 ml

290 ml

280 ml

Fuel / Oil Mixture

50:1 Synthetic

NetWeight Dry

Without Bar And Chain

10.8 lbs (4.9 kg)

9.3 lbs (4.2 kg)

9.9 lbs (4.5 kg)

9.4 lbs (4.2 kg)

16" Bar
