LOG HOME BUILDING TOOLS
ACCESSORIES
SPECIFICATIONS KP312 1806B 1002BA
MaximumCapacities
Planing Width:
12-1/4" (31 cm)
Planing Depth:
1/8" (.35 cm)
Planing Width:
6-3/4" (17 cm)
Planing Depth:
1/16" (.2 cm)
Planing Width: 4-3/8" (11 cm)
Planing Depth: 5/32" (.4 cm)
Curve Radial Cuts: 11-3/16" (30 cm)
Curved Radius: 12-19/32" (32 cm)
No Load Speed 12,000 RPM 15,000 RPM
AMPS (120V) 15.0 A 10.9 A 9.6 A
Overall Length 21-3/4" (55 cm) 20-3/4" (53 cm) 13-5/16" (34 cm)
NetWeight 40.6 lbs (18.4 kg) 40.6 lbs (18.4 kg) 11.5 lbs (5.2 kg)
• Unrivaled for power, size and performance
• Larger and sturdy sole plate for added stability
• Front roller for easy moving over rough materials
• Guide rule for accurate and maximum use
of planing width
• Poly "V" belt designed with grooves efficiently
transfers power from the motor to the blades
• Large ejection chute provides high rate of
chip discharge
• Large Planing Width engineered for an Even Cut
• Precision machined base for notching out logs
at a 12-5/8" curved radius
• Planes 4-3/8" width and 3/16" deep in a single pass
• Large ejection chute for high rate of chip discharge
• Conveniently located front and rear grips for
operator control
• Lock-On Button enables easy continuous operation
• Smoothes and notches out logs for a perfect fit
• Large conveniently located depth settings knob
for easy adjustments
12-1/4" Planer
KP312
4-3/8" Planer
1002BA
6-3/4" Planer
1806B
• Unrivaled for power, size and performance
• Large Base Plate for maximum stability
• Machined Aluminum Base for planing accuracy
• Depth Adjustment Knob for precision
planing applications
• Lock-On Button enables easy continuous operation
Includes:
Wooden
Carrying
Case
Planer Blades
Bevel Guide
Blade Gauge
Assembly
Sharpening
Holder
Assembly
Dressing
Stone
See page 32 for more details
2-Blade cutter head makes
24,000 cuts per minute
For even stock removal
over dips & rises in wood
30,000 cuts per minute
