27 / 40
When QUALITY Counts - ChooseMakita
Outdoor
Power Equipment
ELECTRIC
POWER
CORDLESS
POWER
n QUALITY& SERVICE Counts – ChooseM kita
See page 32 for more
LOGHOME BUILDING TOOLSACCESSORIES
• Cuts lap joints up to 5-1/8"
• Notches or cuts holes in thick wood
stock quickly, cleanly and accurately
• Quick horizontal chain lever for
widening holes
• Base mounts onto a max. 12" beam
• Large adjustable vise for attaching
firmly onto logs
Perfect for timber
framing and log
home building
SPECIFICATIONS
DLM431Z
Capacities
Max Hole Width (Longitudinal):
5-1/8" (13 cm)
Max Hole Width (Transverse):
1-1/4" (3.1 cm)
Max Hole Depth: 6-1/8" (15 cm)
No Load Speed
3,200 RPM
AMPS (120V)
10.5 A
Overall Length
20-1/8" (51 cm)
NetWeight
38.1 lbs (17.3 kg)
SPECIFICATIONS
DTD170Z
Battery Capacities
18V Li-Ion
Hex Shank
0 - 3,600 / 3,200 / 2,100 / 1,100 RPM
Impacts Per Minute
0 - 3,800 / 3,600 / 2,600 / 1,100 IPM
MaximumFastening
Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8" (11.7 cm)
NetWeight
2.0 lbs (0.9 kg)
Chain
Mortiser
7104L
3,200
RPM
ACCESSORIES
• eXtreme Protection Technology (XPT) offers maximum protection against
dust, debris and liquids for optimal performance in extreme conditions
• 4 stage impact power selection + TEK and 'Cam-Out' modes to ensure
precise fastening and prevent damage to fasteners
• 'Cam-out' elimination mode operates at low speed until fastening begins to
eliminate 'cam-out' and cross-threading
• TEK mode reduces impact power during final stages of fastener seating
• LED charge level indicator displays approximate remaining battery power
Features NEW 'Cam-Out'
elimination mode and
ULTRA-COMPACT DESIGN
1/4" Impact
Driver
DTD170Z
Tool only. Battery & charger sold separately.
Threaded
Rod Sockets
Hollow Sockets
See page 32 for more details
25
