28 / 40
4-STROKE
POWER
GENERATORS
makita.ca
26
• Case-hardened steel timing chain allows for precision timing and maximum durability
• Heavy-duty piston rings and a cast-iron cylinder liner resist wear and ensure a long engine life
• Hardened steel rocker arms with precision tappet adjusters are used for greater durability and reduce
service requirements
• Dual ball bearing crankshaft offers maximum durability under load
• Chain-driven overhead cam design offers superior power and performance with an automatic
decompression system to reduce the required pulling force by 30% to 40%. EX engines start easily – even in
cold Canadian winters.
• Cooling fins cast into the interior and exterior of the block maximize surface area for superior engine cooling
• Electronic ignition, low oil shut-off and automatic idle / full power throttle control
Why professionals prefer Makita
generators powered by
EX series
Subaru-Robin™4-cycle engines
Electric
start
653
CC
Generator
G12000R
Starting battery not included
12,000W 7,100W
404
CC
Generator
EG711A
8.2 Hours
of continuous operation
6.6 Hours
of continuous operation
SPECIFICATIONS
G12000R
EG711A
MaximumOutput Current
12,000W (100 / 50 AMP)
7,100W (59.2 / 29.6 AMP)
Rated Output Current
9,500W / 79.2 / 39.6 A
5,000W / 41.6 / 20.8 A
ACVoltage
60 Hz (120V / 240V)
DCVoltage
12 VDC (8.3 AMP)
Displacement
653cc
404cc
MaximumPower
22 HP @ 3,600 RPM
12.5 HP @ 4,000 RPM
Fuel Tank Capacity
44 L
22 L
Noise Level
77 dB
75.5 dB
Overall Length
32.5" (82.6 cm)
28-1/2" (72.5 cm)
DryWeight
310.0 lbs (141 kg)
189.6 lbs (86 kg)
GENERATOR
FEATURES & BENEFITS
G12000R
FEATURES IDLEMODE
EG711A
Receptacles
Duplex 120V (20 AMP), Locking 120V (20 AMP)
Locking 120V (30 AMP), Locking 120V / 240V (30 AMP)
Generator
Full copper windings, AC & DC circuit breakers,
Automatic Voltage Regulator
Engine
EX series Subaru-Robin™ 4-cycle engine
