POWER
CUTTERS
OPTIMUM™Diamond Blades
Blade
Diameter Arbor Rim Type Wet /
Dry Material Type
Application
Max.
RPM For Model(s)
Part No.
16"
1"
20 mm
Segmented
Rim
Wet or
Dry
Medium Cured Concrete, Block,
Brick, Masonry
4,800
RPM EK8100
A-94742
Soft
Asphalt, Green
Concrete, Sand Stone
A-94661
14"
1"
20 mm
Turbo Rim
Wet or
Dry
Hard
Granite, Ceramic, Stone
5,400
RPM
4114
EK6101
EK7301 / HD
EK7651H / HD
A-94627
Segmented
Rim
Medium Cured Concrete, Block,
Brick, Masonry
A-94736
Medium & Soft
(Dual Purpose)
Concrete & Asphalt
T-01270
Soft
Asphalt, Unset
Concrete, Sandstone
A-94655
12"
1"
20 mm
Segmented
Rim
Wet or
Dry
Medium Cured Concrete, Block,
Brick, Masonry
6,300
RPM
4112H
DPC6430
A-94720
Medium & Soft
(Dual Purpose)
Concrete & Asphalt
T-01264
ER CUTTER
ACCESSORIES
Segmented Rim
General purpose quick cutting blade for
concrete, tile, brick & stone
Turbo Rim
Fast and clean cutting blade for
all applications
OptimumDiamondBlades
Optimum Bond Matrix provides the optimal balance between wear, fracture and
exposure in order to maximize the cutting ability of the diamond content
makita.ca
14" Metal Cutting Blade for Power Cutters
A-96229
• Offers up to 100x the life of abrasive wheels
• Ideal for cutting angle iron, rebar, deck plating, steel studs,
pipe and more!
• Premium diamond content for long life and fast cutting
• Expertly balanced premium steel core for reduced vibration and noise
• Vacuum brazed diamond segments for optimum operational life and
consistent performance
• Eliminates performance issues of abrasive wheels, including disc
shrinkage, glazing and shattering
• Segmented Rim style reduces heat buildup and maximizes
material removal
14" 3DPREMIUMDiamond Blade
T-02836
• Features 3D Diamond Grid Technology incorporating even
placement of diamond content throughout the segment
• 3D pattern releases worn diamond and exposes sharp diamond
at a consistent rate
• Offers premium professional performance versus traditional
diamond blades
• Keyhole expansion slots promotes blade cooling
• Laser welded segments ensure the strongest possible joint
• Segmented style rim
• Ideal for concrete, asphalt, brick and block
PREMIUMPROFESSIONAL
PERFORMANCE
FASTESTCUTTING
MORECUTS
FASTEST CUTTING
FASTEST CUTTING
MORE CUTS
