112 / 220
WOODWORKING
makita.ca
110
STANDARD EQUIPMENT INCLUDES:
4" x 24"Abrasive Belt 80G (1 Ea. 742322-9), Dust Bag (122562-9), Cork Rubber Plate (421646-3), Steel Plate (344620-3)
Labyrinth Construction Prevents Motor Contamination
• Powerful Motor for high production applications
• Streamlined Right Side design enables easy flush sanding against walls
• Power Cord located on upper portion of rear handle for operator convenience
• Dust Bag rotates 360° for optimal placement during operation
• Ergonomically Designed Round Front Grip for increased operator control and comfort
4˝ x 24˝ Belt Sander
SPECIFICATIONS
Belt Size
4" x 24" (100 mm x 610 mm)
Belt Speed
1,640 ft./min. (500 m/min.)
AMPS (120V)
11.0 A
Overall Length
13-7/8" (353 mm)
Cord Length
16.4 ft. (5 m)
Net Weight
12.6 lbs (5.7 kg)
9403
STANDARD EQUIPMENT INCLUDES:
3" x 24"Abrasive Belt 80G (1 Ea. 742312-8C), Dust Bag (122296-4), Cork Rubber Plate (423035-8), Carbon Plate (423036-6)
Durable Design For Heavy Duty Applications
• Extended Base allows flush sanding
• Innovative Design for sanding flush to walls using nose and side of sander
• Quick and Easy Belt Changes using Belt Tensioning Lever
• Precision Belt Tracking Knob for easy adjustment of belt position
• Extra Long Power Cord for easy maneuverability
3˝ x 24˝ Belt Sander
SPECIFICATIONS
Belt Size
3" x 24" (76 mm x 610 mm)
Belt Speed
1,300 ft./min. (396 m/min.)
AMPS(120V)
7.8 A
Overall Length
14" (355 mm)
Cord Length
16.4 ft. (5 m)
Net Weight
10.6 lbs (4.8 kg)
9924DB
STANDARD EQUIPMENT INCLUDES:
Abrasive Belt 2 Ea.: (#40; 742301-7, #60; 742302-5, #80; 742303-3, #100; 742304-1, #120; 742305-9), Side Handle (153489-2)
• Narrow Belt and Exposed Front Pulley for use in
close quarters or on irregular shapes
• Multi-position Side Handle for comfortable
operational versatility
• Lock-On Button enables easy continuous
operation
1-3/16˝ x 21˝ Belt Sander
SPECIFICATIONS
Belt Size
1-3/16" x 21"
(30 mm x 533 mm)
Belt Speed
660 - 3,300 ft./min.
(200 - 1,000 m/min.)
AMPS (120V)
5.0 A
Overall Length
15" (380 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
4.6 lbs (2.1 kg)
9031
STANDARD EQUIPMENT INCLUDES:
Abrasive Belt 80G (2 Ea.A-34469)
Power File / Sander Ideal For
Use In Confined Spaces
• 1/4" (125157-7), 3/8" and 1/2" (125159-3) width
Sanding Arms available for use in a variety
of applications
• Variable Speed Dial adjusts cutting speed based
on materials or application
• Precision Belt Tracking Knob for easy adjustment
of belt position
• Quick and Easy Belt Changes using Belt
Tensioning Lever
• Sanding Arms can be swiveled up to 90°
downwards or 10° upwards for maximum
operational versatility
• Slim Tension Roller enables sanding and
filing in confined areas
Variable Speed
3/8˝ x 21˝ Belt Sander
SPECIFICATIONS
Belt Size
3/8" x 21"
(9 mm x 533 mm)
Belt Speed
980 - 5,600 ft./min.
(300 - 1,700 m/min.)
Maximum Sanding Depth 4-5/16" (110 mm)
AMPS (120V)
4.4 A
Overall Length
16-1/2" (420 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
3.5 lbs (1.6 kg)
OPTIONAL ACCESSORIES
1/4" Arm Assembly (125157-7)
1/2" Arm Assembly (125159-3)
9032
Flat Top Design For Use As An Inverted Stationary Sander
• Variable Speed Dial adjusts sanding speed based on materials or applications
• Quick and Easy Belt Changes using Belt Tensioning Lever
• Auto-Track Belt System centers sanding belt automatically
• Streamlined Right Side design enables easy flush sanding against walls
• Ergonomically Designed Front Grip for increased operator control and comfort
Variable Speed
SPECIFICATIONS
Belt Speed
690 - 1,440 ft/min
(210 - 438 m/min)
AMPS (120V)
8.8 A
Cord Length
16.4 ft. (5 m)
9404:
Belt Size 4" x 24" (100 mm x 610 mm)
Overall Length
13-1/8" (334 mm)
Net Weight
10.6 lbs (4.8 kg)
9920:
Belt Size 3" x 24" (76 mm x 610 mm)
Overall Length
13-1/8" (334 mm)
Net Weight
9.9 lbs (4.5 kg)
9903:
Belt Size 3" x 21" (76 mm x 533 mm)
Overall Length
11-5/8" (296 mm)
Net Weight
9.5 lbs (4.3 kg)
4" x 24"
STANDARD EQUIPMENT INCLUDES:
4" x 24"Abrasive Belt 80G (1 Ea. 794133-C-2),
Dust Bag (122591-2),
Cork Rubber Plate (423314-4),
Carbon Plate (423317-8)
9404
STANDARD EQUIPMENT INCLUDES:
3" x 21"Abrasive Belt 80G (1 Ea. 742308-3),
Dust Bag (122591-2),
Cork Rubber Plate (423312-8),
Carbon Plate (423315-2)
9903
9920
STANDARD EQUIPMENT INCLUDES:
3" x 24"Abrasive Belt 80G (1 Ea. 742312-8C),
Dust Bag (122591-2),
Cork Rubber Plate (423313-6),
Carbon Plate (423316-0
9404, 9920, 9903
Belt Sanders
Belt
Size
3" x 21"
Belt
Size
3" x 24"
Belt
Size
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
Variable Speed Control
